The rangehood works with
. . . air extraction:
The air is drawn in, cleaned by the
grease filter and then directed outside.
If the on-site ventilation system does
not have a non-return flap, then the
non-return flap supplied with the
appliance must be fitted in the exhaust
socket in the motor unit.
Having a non-return flap fitted in the
ducting ensures that air, once ducted
to the outside, cannot get back into the
room again.
The flap is closed when the rangehood
is switched off.
When the rangehood is switched on,
the non-return flap opens for the
cooking vapours to be blown directly
outside.
Please note, the performance of
this rangehood hinges greatly on
the installed ducting to vent the
vapours. Poor choice of ducting
results in poor rangehood
performance. For ducting
recommendations, please refer to
the relevant section in these
operating instructions or contact a
specialised installer.
. . . air recirculation:
(air recirculation conversion kit required)
The air is drawn in and cleaned first by
the grease filter and then by a charcoal
filter. The cleaned air is then recirculated
back into the kitchen.
Charcoal filters are available to order
through your Chartered Agent or from
Miele or via the internet at
www.miele-shop.com (check availability).
See back cover for contact details and
"Technical Data" for model number.
Before using the rangehood in
recirculation mode, ensure that the
charcoal filter is in place; see
"Cleaning and care".
Description of the functions
12

Miele DA 3160 Specifications

General

Intensive speed	Yes
Number of speeds	3
Type of extraction	Ducted
Maximum extraction power	550 m³/h
Housing material	Stainless steel
Bulb type	Halogen
Bulb power	50 W
Number of bulbs	2 bulb(s)
Power requirements	230/50

Weight and Dimensions

Depth	275 mm
Width	595 mm
Height	409 mm
