Master Chef Ovens
5.29 Catalyst Insert (P/Self Clean Models) - Removal
1. Remove the Front Doors (Section 5.2).
2. Refer to Figure 5-21
3. Loosen the Upper Heating Element Knurled Nut (Item 1)
4. Carefully pull the Upper Heating Element downwards.
5. Loosen the Retaining Screws on the Catalyst Retaining Plate (Item 2).
Note
Protect the floor of the oven when removing the Catalyst Retaining Plate.
The Catalyst Insert may fall from the cavity opening. Be prepared to
remove the insert.
6. Remove the Catalyst Retaining Plate to access the Catalyst Insert.
7. Remove the Catalyst Insert from the opening.
Figure 5-21: Catalyst Insert - Removal
1. Element Retaining Knurled Nut
2. Retaining Bolts
