Miele H6600BM User Manual

Symbols
The following symbols may also appear in the display in addition to the text:
Symbol Explanation
N Minute minder
- Allocates an illuminated C to an option and indicates that
the option can be selected.
#
If more than four options are available a bar will appear on
the right-hand side of the display.
Use the allocated sensors to scroll through the list.
ZZZZZZZZZZZZZZ The end of a list is indicated by a dotted line. By scrolling
down further, you reach the beginning of the list again.
P P P P G G GM Some settings, e.g. display brightness and buzzer volume
are selected using a bar chart.
( A tick shows that a setting is active.
"-" will not appear in front of it and the sensor belonging to it
will not be illuminated.
: This symbol indicates that there is additional information and
advice about using the oven.
Select "OK" to access the information.
0 The system lock is on (see "Settings - Safety"). The oven
cannot be used.
Controls
28

Miele H6600BM Specifications

General

Style	single
Color	stainless steel
Total Capacity	1.52 cu. ft.
Temperature Probe	yes
Microwave	yes
Convection	yes
Control Type	touch sensor
Interior Light	yes
Kitchen Timer	yes
Power Consumption	2, 200; 1000
Electrical Requirements	240/208v, 60hz, 20a
Voltage	240/208 volts
Current	20

Weight and Dimensions

Depth	22 3/8 inch
Height	17 15/16 inch
Width	23 7/16"
