Miele K 31222 Ui User Manual

Installation
*INSTALLATION*
66
On furniture with door fittings (e.g.
stubs, seals, etc.), the dimension of
these must be taken into account to
ensure there is a gap all round of
42mm.
 Pull the refrigeration appliance for-
wards by the appropriate dimension.
 Check again to make sure there is a
gap of 42mm to the front edges of
the door fittings.
Tip: If possible, remove the door fittings
and push the refrigeration appliance
into the niche until all fixing brackets at
the top and bottom are touching the
front edge of the housing unit side wall.
Aligning the refrigeration appliance
When securing the refrigeration appli-
ance in the niche at the top, it should
sit lightly tensioned between the floor
and the worktop.
 Adjust the front and rear feet altern-
ately according to the height of the
niche and make sure the refrigeration
appliance is correctly aligned.
Proceed as follows:
 Adjust both rear feet with appropriate
screws at the front right and left in the
appliance plinth using a flat-headed
screwdriver.
 Use an Allen key to unscrew both
front feet.
Tip: As soon as the feet have been un-
screwed slightly, you can adjust them
with a screwdriver at the bottom of the
foot (see small illustration).

Miele K 31222 Ui Specifications

General

Door hinge	Right
Control type	Buttons
Product color	-
Reversible doors	Yes
Appliance placement	Built-in
Door panel included	No
Fridge door balconies	2
Number of vegetable drawers	1
Fridge number of shelves/baskets	4
Lamp type	LED
Cord length	1.9 m
Noise level	35 dB
Climate class	SN-ST
Fridge net capacity	137 L
Fridge gross capacity	- L
Current	10 A
Connected load	- W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Annual energy consumption	115 kWh

Weight and Dimensions

Depth	552 mm
Width	597 mm
Height	818 mm
Weight	38100 g
Installation compartment depth	550 mm
Installation compartment width	600 mm
Installation compartment height	870 mm
