Miele K 31222 Ui User Manual

Installation
*INSTALLATION*
68
Securing the appliance in the niche
1.Secured at the top
2.Secured at the side
 Screw the appliance into position on
the right and the left.
Fitting the furniture door
If fitted in a run of units make sure that
the top edge of the furniture door is at
the same height as neighbouring unit
doors.
The furniture door must be fitted cor-
rectly and not under tension.
The next section gives instructions on
how to fit a furniture door that is at
least 16–19 mm thick.
Ensure that the plinth facing is refitted
correctly.
 The distance between the appliance
door and the fixing bracket is set to
8mm at the factory. Check this dis-
tance and adjust it if necessary.
 Push the fitting aids up to the
height of the furniture door: the lower
edge X of the fitting aids must be at
the same height as the upper edge of
the furniture door being fitted (see
in diagram).

Miele K 31222 Ui Specifications

General

Door hinge	Right
Control type	Buttons
Product color	-
Reversible doors	Yes
Appliance placement	Built-in
Door panel included	No
Fridge door balconies	2
Number of vegetable drawers	1
Fridge number of shelves/baskets	4
Lamp type	LED
Cord length	1.9 m
Noise level	35 dB
Climate class	SN-ST
Fridge net capacity	137 L
Fridge gross capacity	- L
Current	10 A
Connected load	- W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Annual energy consumption	115 kWh

Weight and Dimensions

Depth	552 mm
Width	597 mm
Height	818 mm
Weight	38100 g
Installation compartment depth	550 mm
Installation compartment width	600 mm
Installation compartment height	870 mm
