Installation
*INSTALLATION*
59
Use a level to check that the washing
machine is standing level.
Hold foot 1 securely with a pipe
wrench. Turn counter nut 2 again us-
ing the spanner supplied until it sits
firmly up against the housing.
Risk of damage due to incor-
rectly aligned washing machine.
There is a danger of the washing ma-
chine moving about if the feet are not
secured.
Turn all 4 counter nuts for the feet
until they sit firmly up against the
housing. Please also check this for
the feet which did not need adjust-
ment.
Holding bracket for plinth
The holding bracket prevents the wash-
ing machine from falling off the plinth
during operation.
Fastening with the holding bracket is
only intended for plinths made from
concrete. The plinth must be flat and
level. The surface below the plinth must
be able to withstand the physical loads.
Prior to installation, check whether the
plinth complies with the minimum di-
mensions.
Height: 6cm
Width: 60cm
Depth: 65cm
Positioning the holding bracket
Risk of injury from sharp edges.
The holding bracket has sharp
edges. You could cut yourself on the
edges.
Take care when handling the holding
bracket.
Wear gloves while installing the hold-
ing bracket.
The front appliance feet must protrude
by at least 3mm. The washing ma-
chine must already be aligned (see
“Installation – Aligning the washing
machine”)
