Installation and connection
67
Water drainage
The suds are drained through a drain
pump with a 1m delivery head. For the
water to drain freely, the hose must be
free of kinks.
If required, the hose can be extended to
a length of up to 5m. Accessories are
available from Miele or from your Miele
dealer.
For a delivery head of more than 1m
(up to a max. of 1.8m) a replacement
drain pump will need to be fitted.
Please contact Miele for advice.
For a delivery head of 1.8 m the hose
can be extended to a length of up to 2.5
m. Accessories are available from Miele
or from your Miele dealer.
Drainage options:
1. Directed into a sink or basin:
Please note:
– Hook the hose over the edge and
secure it.
– If the water is pumped into a
washbasin, make sure that it can
drain away freely. Otherwise there
is a risk of water overflowing or of
some of the drained water being
sucked back into the machine.
2. Connected securely to a plastic drain
pipe with a rubber nipple (there is no
need to use a siphon).
3. Connected securely to a floor drain
(gully).
4. Connected securely to a washbasin
with plastic nipple.
Please note:
a
Adapter
b
Spigot nut
c
Hose clip
d
End of the hose
Fit adapter to the sink drain outlet
using nut .
Attach the end of hose to adapter
.
Use a screwdriver to tighten hose clip
up close to the nut.
