Pellerin Milnor Corporation 31
Table 21. Parts List—Motor Mount
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
Reference Assemblies
A GDB30009 3022T6X DRIVE BASE INSTALL 3015/3022T6X
B GDB30008 3022V8 DRIVE BASE INSTALL 3015/3022VRJ, V8Z
C GDB30008A 30VZ DRIVE BASE INSTALL 3015/3022VZZ
Components
all 1 02 04256 PLATE=MOTOR MNT, 3022S4
A 2 02 04554 BRKT=MOTOR MOUNT 3015/22T6X
BC 2 02 04551 BRKT=MOTOR MOUNT 3022V8
all 3 02 04258 SHAFT=MOTOR MOUNT, 3022S4
all 4 54E226 FLBRNYL 3/4"X1"X1";EA=1 FLGBRG
all 5
54JH10750C SHFTCOLLAR 3/4"CLPTYP(SGLSPLT)
all 6 15K153H INDHEXFLGSCR1/2-13X1+1/4GR8ZN W/LOCTITE
all 7
15G222B HEXFLGNUT 1/2-13 ZINC SERRATED
A 8 02 19288A BRACKET=SPRING MOUNT - 1.93X2.25
BC 8 02 19288 BRACKET=ADJUSTING-1.5X1.75
all 9 02 04258A ROD=MOTOR MOUNT SPRING
all 10 54J010 SHFTCOLL G#1F506 1/2"ID EA=1PC
all 11 02 04259 SPRNG/MOT MOUNT/3022S4#SPC2690
A 12 02 03839B PLATE=MTR MNT REINFORCEMENT
all 13 15K092 HEXFLGSCR 3/8-16X1 GR8 CS
all 14 15G198 HXFLGNUT 3/8-16 ZINC
all 15 15U240 FLATWASHER(USS STD) 3/8" ZNC P
Motor Mount
2 Sheets
30015T6X,VRJ,V8Z,VZZ and 30022T6X,VRJ,V8Z,VZZ
Drive Assemblies
