Milnor 30022VRJ User Manual

58
Pellerin Milnor Corporation
MCR27E5, MWR27E5, MWF27J8, MWF27Z8; 3015T6X,VRJ,V8Z,VZZ; 30022T6X,VRJ,V8Z,
VZZ; 30022X8R; 36021V5Z, V7Z; 36026V5Z, V7Z; 42026 & 42030V6Z
Legend
D...Door lock switch
E...Door closed switch
F...Door lock solenoid
G...See details A & B
H...See detail C
Door Lock Mechanism
2 Sheets
30015T6X,VRJ,V8Z,VZZ and 30022T6X,VRJ,V8Z,VZZ
BPWOAD03 / 2019406
BPWOAD03.1 0000255709 B.2 F.2 11/15/19 10:30 AM Released
Door Assemblies
