Pellerin Milnor Corporation 67
Table 30. Parts List—Soap Chute
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
Reference Assemblies
A SA 33 058M 94000Z ASSY=PLSTC SOAP INLET
Components
all 1 02 03130 BRACKET=PLASTIC SOAP INLET
all 2 02 03304D GASKET=SOAPCHUTE 1/8" EPDM BL
all 3 02 03589I PLASTIC SHELLSIDE SOAP INLET
all 4 02 03589T BACKING RING=PLSTC CHEM INLT
all 5 02 03594 GUARD SOAP CHUTE=CWU
all 6 02 03595 PIN SOAP CHUTE HINGE=CWU
all 7 02 03630A SPLASH GUARD= SOAP CHUTE
all 9 02 03593 89432B LID-SOAPCHUTE CWE TY304 SS
all 10 15N133 RDMACSCR 10-24UNCZA X5/8" SS18
all 11 15U160 LOCKWASHER MEDIUM #10 SS18-8
all 12 15G130 HEXMACHSCRNUT 10-24UNC2 SS18-8
all 13 15P050 PHDCUT-F PANHD 10-32X3/4 SS410
all 14 24G018N ROLLED WASH.194ID NYLTITE 10W
all 15 15P051 TRDFRM AB HOLTHD 10-16X3/4SS41 PRECOAT 80
PATCH
Soap Chute
2 Sheets
30015T6X,VRJ,V8Z,VZZ and 30022T6X,VRJ,V8Z,VZZ
Chemical Supply Devices
To Next Page
