Table 31. Parts List—Peristaltic Supply Inlets
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
Reference Assemblies
A SA 33 057 ASSY=PLSTC PERSTL REAR INLET 3022V8 30015VRJ,V8Z
30022VRJ,V8Z
B SA 33 057B 30T6X PERISTALTIC REAR INLET ASSY 30015T6X
30022T6X
Components
all 1 27A074S HOSECLAMP 2+1/16-3"SSSCR#64040
all 2 02 03585D 3022V8 PARISTALTIC/WATER INLET HOSE
all 3 27A082S HOSECLAMP 2+9/16-3.5SS305SCR
all 4 02 03585A PARISTALTIC/WATER INLET 30
all 5
51PB0GNA 3/8" PVDF THRD PLUG
all 6 27A090S HOSECLAMP 13/16-1.5"SS#64016B
all 7 60E010 TUBINGPOLYBRAID 1"X1.312
all 8 60E006C PVC TUBING NYL.REINF.5IDX.75OD
all 9 27A040 HOSECLAMP 7/16-25/32SS W/SCREW
all 10 51E510N HOSEADP 1/2"HX11/16 W/NUT=NYL
all 11 60E008A TUBINGNYLREINF.75"IDX1.025"OD
all 12 27A044S HOSECLAMP 11/16-1.25SSCR#64012
all 13 51E513N HOSEADPT3/4"HX11/16 W/NUT=NYL.
all 14 51E513NU NUT 11/16 THRD.#64138 US PLAST
all 15 02 03585G 3022V8 PERIST MTG BRKT
all 16 15K085 HEXCAPSCR 3/8-16UNC2AX3/4 GR5
all 17 15G198 HXFLGNUT 3/8-16 ZINC
all 18 15K031 BUTSOKCAPSCR 1/4-20X1/2 SS18-8
all 19 15U181 LOCKWASHER MEDIUM 1/4 SS18-8
all 20 15U188 FLTWASH 1/4 STD COMM SS18-8
all 21 12P11JSB SNAPBUSH 1.50"MH X 1.312 HEYCO#2240
all 22 60C121 GROMMET-FILLTUBE3015/22
all 23 02 03586 PERISTALTIC/WATER SPOUT
all 24 12P015B TRW BLK NYL PUSH FAST
all 25 12P11AHP HOLEPLUG LPE BLACK 1" #BPF
Peristaltic Supply Inlets
3 Sheets
30015T6X,VRJ,V8Z,VZZ and 30022T6X,VRJ,V8Z,VZZ
