Table 34. Parts List—Brass Water Valve Assembly
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this letter or
the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
Reference Assemblies
A SA 33 056 3022V8 BRASS WATER VALVE ASSY
Components
all 1 W2 03588T 3022V8 BRASS H20 MNT WLMT
all 2 51E513A 3/4"MHX1/4"FP PARKER#78GH-12-4
all 3 5N0E03KBE2 NPT NIP 1/4X3.5 TBE BRASS STD
all 4 27A0650CLP TUBING CLP 1/2"OD #PS1200-1/2
all 5 96P058A71 1/4"NPT X 1/8"ORIFICE 240V 5/6
all 6 51E507D HOSESTEM BRASS 1/4MPX5/8HOSEID
all 7
27A044S HOSECLAMP 11/16-1.25SSCR#64012
all 8 60E007C TUBING NYL.REINF.5/8"IDX.8750D
all 9 51E513C 3/4"MHX3/4"FPT-PARKER#81GH-12-12
all 10 5N0P05AB42 NPT NIPPLE 3/4X5 TBE BRASS STD
all 11 5N0P06ABE2 NPT NIP 3/4X6 TBE BRASS STD
all 12 27A0050 CLP-RGDSTL COND #PS1100-1/2
all 13 96P056B71 3/4"NC 230V50/60 W/LEADS BURKERT#5281
all 14 51E511 HOSESTEM BRASS 3/4MP X HOSEID
all 15 60E008A TUBINGNYLREINF.75"IDX1.025"OD
all 16 12P11KSB SNAPBUSH 1.50" X 1.06" #22MP15017
all 17 12P11CSB SNAPBUSH 1.093"MH X .94"ID HEYCO#2166
all 18 60C020 RUBGRO #2802 1-5/161DX1-5/8 X1/8
all 19 60C121 GROMMET-FILLTUBE3015/22
Brass Water Valve Assembly
2 Sheets
30015V8Z, 30022V8Z
Water and Steam Piping and Assemblies
To Next Page
