Pellerin Milnor CorporationPellerin Milnor Corporation
P. O. Box 400, Kenner, LA 70063-0400
Litho in U.S.A.
Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to
assemblies are referred to in the "Used In" column to identify which components belong to an assembly. The item
numbers(1, 2, 3, etc.) assignedto components relate the partslist tothe illustration.
Parts List—Drain Valve Installation
BMP010014/2012383B
(Sheet 2 of 2)
---------------------------------------------------------------------ASSEMBLIES------------------------------------------------------------------
A REFERENCE 36021V5J, 36026V5J
B REFERENCE 36021V7J, 36026V7J
42026V6J, 42030V6J
-------------------------------------------------------------------COMPONENTS------------------------------------------------------------------
all 1 W2 03974A *WLMT=3022F8 RIGID DRAIN PIPE
all 2 02 04197A DUMP VALVE MT BKT
all 3 60B075 DFW56-33PMSP RUBB CONN.
all 4 96D350A37C DRNVAL 3"N/O 120V50/60C W/COVER
A 5 60E303A03K HOSE=3"ID X 3+1/2"LG
B 5 60E303A05A HOSE=3"ID X 5"LG
all 6 27A075A T-BOLT HOSECLAMP 3.03-3.34"
A 7 60E303A26A HOSE=3" ID X 26 LG
B 7 60E303A41K HOSE=3"I.D. X 41.5 LG
all 8 27A077A T-BOLT HOSECLAMP 3.37-3.68"SS
all 9 15N110H RDWASHHD TORXBOLT M6-1X25MM ZN
all 10 15G004HB EXTRUNUT M6-1 GRIP 0.8-4MM
all 11 15G004HC EXTRUNUT M6-1 GRIP 3.5-6.5MM
all 12 15P201 TRDCUT-F HXWASHD 3/8-16X1N1K
all 13 15G205 HXNUT 3/8-16UNC2B ZINC GR2
104
