Milnor 48040M7K User Manual

20
Pellerin Milnor Corporation
Table 4. Components that Become Worn
Mark
Do this each
Component
More Data
1 2 3 4
5
6
x
200 hours drive belts and pulleys See Section 3.2.1 , page 27
x
200 hours tubes and hoses (non-
hydraulic)
Examine hoses and hose connections for leaks.
x
200 hours hydraulic hoses See Section 3.4.3 , page 42
x
1200 hours door bumpers Replace if damaged.
x
200 hours rubber springs See Figure 24, page 40
x
200 hours shock absorbers See Section 3.3.4 , page 40
x
1200 hours tilt bumpers See Figure 22, page 38 Examine. Replace if damaged or
worn.
3.1.1.5 Bearings and Bushings
BNUUUH01.R13 0000399388 A.5 A.26 11/16/21 11:04 AM Released
Unless the item is sealed, apply grease to prevent damage. See the next section for motors.
Table 5. Bearings and Bushings
Mark
Do this each
Component More Data . See also Section 3.1.3 , page 22
1 2 3 4
5 6
Grease plate 01 10025Y for bearing housing. Use this data if your machine has this grease plate. See Figure 20, page 37
and Section 3.1.5 , page 24. It is necessary to remove a side panel on some models, to access this grease plate.
x
200 hours seal Add 0.12 oz. (3.6 mL) of grease EPLF2 (Table 9, page
23)
x
200 hours rear bearing Add 0.3 oz. (9 mL) of grease EPLF2
x
200 hours front bearing Add 0.3 oz. (9 mL) of grease EPLF2
Other Grease Ports
x
200 hours hydraulic door bushings Figure 21, page 37. Add 0.06 oz. (1.8 mL) of grease
EPLF2 (Lubricant Identification)
x
200 hours door hinge Figure 21, page 37. Add 0.12 oz (3.6 mL) of grease
EPLF2 (Table 9, page 23).
x
200 hours door latch plunger Figure 21, page 37. Apply stick DE3 (Table 9, page 23)
to surface.
x
200 hours door open plunger Figure 21, page 37. Apply stick DE3 (Table 9, page 23)
to surface.
x
200 hours lower pivot for hydraulic
cylinders—one place,
each side
Figure 22, page 38. Add 0.06 oz. (1.8 mL) of grease
EPLF2 (Table 9, page 23).
none
upper pivot for hydraulic
cylinders
Figure 22, page 38. No grease maintenance necessary.
none
front tilt pivot
x
600 hours motor and pump bearings See Section 3.1.6 : Procedures for Motors, page 24
3.1.1.6 Motor Grease Schedule
BNUUUH01.R15 0000399408 A.5 A.26 10/21/21 10:14 AM Released
Use the data in Table 10: Motor Grease Intervals and Quantities, page 26 to complete this table.
Routine Maintenance
