14 | minnkotamotors.com
©2019 Johnson Outdoors Marine Electronics, Inc.
COPILOT
b. Press and hold the Learn Button and power up the
CoPilot receiver by reconnecting the Power Cables, or
by making sure that the breaker, if equipped, is "on."
c. Continue to hold the Learn Button down for 10
seconds. During this time the receiver audio will
emit a warble sound, slowly transition to a constant
beep and then shut off.
d. Release the Learn Button and the receiver will
reboot. The receiver will emit a 2 second long beep
indicating memory is empty. This audio pattern
will occur each time the receiver powers up until a
remote ID number is "Learned."
Learn Button
Right Sideplate
REPLACING THE BATTERY
a. Temporarily ground yourself by touching a grounded
metal object in order to discharge any static
electricity in your body.
b. Remove the four screws on the bottom of the
remote case.
c. Separate the case halves to access the circuit board.
NOTICE: The replacement battery must be
a model CR2032 coin cell type. It is strongly
recommended that a name brand battery is used.
d. To remove the Battery, place the tip of a finger or
thumb under the exposed edge of the Battery and
pry it upwards.
e. Install the new battery with the positive (+) side
of the Battery facing up and away from the Circuit
Board. Ensure Battery is snapped securely in place.
Retaining Fingers
Circuit Board
Remote
Case Front
Screws
NOTICE: The replacement battery must be a model
CR2032 coin cell type. It is strongly recommended
that a name brand battery is used.
Battery
1
2
2
