MODEL: HD-6000

Page 11

ELECTRICAL ADJUSTMENTS

Note: Perform only the adjustments required.

Do not attempt an alignment if proper equipment is not available.

Test Equipment

• Oscilloscope (Unless otherwise specified, use 10:1 probes)

• Signal Generator (both SD and HD capable)

Test Signal

A. Color Bar Signal

Use the color bar signal shown below, unless otherwise specified in this manual.
