Mitsubishi Electric MSZ-BT35VG Service Manual

4
SPECIFICATION
3
Indoor model
MSZ-BT20VG
MSZ-BT20VGK
MSZ-BT25VG
MSZ-BT25VGK
MSZ-BT35VG
MSZ-BT35VGK
MSZ-BT50VG
MSZ-BT50VGK
Power supply Single phase 230 V, 50 Hz
Electrical data
Power input
1
Cooling
W
19 31
Heating 24 37
Running
current
1
Cooling
A
0.20 0.31
Heating 0.25 0.35
Fan motor
Model RC0J30-CV
Current
1
Cooling
A
0.20 0.31
Heating 0.25 0.35
Dimensions W × H × D mm 838 × 280 × 235
Weight kg 9.0
Special remarks
Air direction 5
Airow
Cooling
Super High
m
3
/h
654 792
High 522 660
Med. 408 540
Low 312 456
Super Low 252 378
Heating
Super High 714 846
High 540 714
Med. 408 594
Low 300 468
Super Low 252 360
Sound level
Cooling
Super High
dB(A)
43 46
High 37 38 40
Med. 30 31 36
Low 22 33
Super Low 19 29
Heating
Super High 43 44 48
High 37 43
Med. 30 38
Low 23 33
Super Low 20 29
Fan speed
Cooling
Super High
rpm
990 1,150
High 840 1,000
Med. 700 860
Low 580 760
Super Low 500 660
Heating
Super High 1,060 1,210
High 860 1,060
Med. 700 920
Low 560 770
Super Low 500 640
Fan speed regulator 5
Remote controller model ZH19A
NOTE: Test conditions are based on ISO 5151.
Cooling: Indoor Dry-bulb temperature 27°C Wet-bulb temperature 19°C
Outdoor Dry-bulb temperature 35°C Wet-bulb temperature 24°C
Heating: Indoor Dry-bulb temperature 20°C Wet-bulb temperature 15°C
Outdoor Dry-bulb temperature 7°C Wet-bulb temperature 6°C
1 Measured under rated operating frequency.
Specifications and rated conditions of main electric parts
Model
MSZ-BT20/25/35/50VG
MSZ-BT20/25/35/50VGK
Fuse (F11) T3.15AL250V
Horizontal vane motor (MV) 12 V DC
Varistor
(NR11) 470 V
Terminal block (TB) 3P
OBH849C
