Mitsubishi Electric MSZ-BT35VG Service Manual

6
OUTLINES AND DIMENSIONS
5
Unit: mm
100.5
242.5
225 225
199.537.5
100.5
52.5
167.5 167.5
366.5 327.5 91.5
3
37.5 199.5
219.5
242.5
23.5
46
18.5
167
838
235 5
280
50
(5) 351.5
66.5 2.5
64
43
57
42
57
164
100
12.5
126.5
98
40
57
677.5 111(49.5)
MIN 37mm
IN CASE OF LEFT, LEFT REAR,OR LEFT UNDER PIPING (USING SPACER), MIN 125mm
MIN 20mm
MIN 7mm
MIN 30mm
INSTALLATION PLATE
11×20 OBLONG HOLE
11×26 OBLONG HOLE
INDOOR UNIT
WALL HOLE
ø 65
AIR OUT
AIR IN
INSTALLATION PLATE
PIPING
DRAIN HOSE
MSZ-BT20/25/35VG MSZ-BT20/25/35VGK
PIPING
INSULATION ø37 O.D
LIQUID LINE
ø6.35 - 0.39m
(FLARED CONNECTION ø6.35)
GAS LINE
ø9.52 - 0.34m
(FLARED CONNECTION ø9.52)
DRAIN HOSE
INSULATION ø29
CONNECTED PART ø16 O.D
MSZ-BT50VG MSZ-BT50VGK
PIPING
INSULATION ø37 O.D
LIQUID LINE
ø6.35 - 0.39m
(FLARED CONNECTION ø6.35)
GAS LINE
ø9.52 - 0.34m
(FLARED CONNECTION ø12.7)
DRAIN HOSE
INSULATION ø29
CONNECTED PART ø16 O.D
MSZ-BT20VG MSZ-BT25VG MSZ-BT35VG MSZ-BT50VG
MSZ-BT20VGK MSZ-BT25VGK MSZ-BT35VGK MSZ-BT50VGK
OBH849C
