Model
Item
FDC71VNX
Power source 220-240V
~
50Hz / 220V
~
60Hz
Operation data Cooling Heating
Nominal capacity kW 7.1 [ 3.2 (Min.)
~
8.0 (Max.)] 8.0 [ 3.6 (Min.)
~
9.0 (Max.)]
Sound Pressure Level dB(A) Cooling : 51 Heating : 48
Exterior dimensions
Height × Width × Depth
mm 750 × 880 (+88) × 340
Exterior appearance
(Munsell color)
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg 60
Refrigerant equipment
Compressor type & Q'ty
RMT5118MDE2 × 1
Starting method Direct line start
Refrigerant oil 0.675 M-MA68
Heat exchanger M shape fin & inner grooved tubing
Refrigerant control Electronic expansion valve
Air handling equipment
Fan type & Q'ty
Propeller fan × 1
Motor <Starting method> W 86 < Direct line start >
Air flow (Standard) CMM Cooling : 60 Heating : 50
External static pressure 0
Shock & vibration absorber Rubber sleeve (for Compressor)
Electric heater W 20 (Crank case heater)
Safety equipment
Internal thermostat for fan motor
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size
mm
Liquid line :
φ
9.52 (3/8")
Gas line :
φ
15.88 (5/8")
Connecting method Flare piping
Refrigerant line (one way) length
Max.50m
Vertical height difference between
outdoor unit and indoor unit
Max.30m (Outdoor unit is higher)
See page 152
Max.15m (Outdoor unit is lower)
Refrigerant Quantity R410A 2.95kg in outdoor unit (incl. the amount for the piping of : 30m)
Drain Holes size
φ
20 × 3pcs
Insulation for piping Necessary (both Liquid & Gas lines)
IP code IP24
Adapted to RoHS directive
Item Indoor air temperature Outdoor air temperature
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C 7˚C 6˚C
Notes (1) The data are measured at the following conditions.
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber. During operation
these value are somewhat higher due to ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 230V50Hz or 220V60Hz.
PJF000Z296
(2) Outdoor units
