Adapted to RoHS directive
FDF71VNXVD
Indoor unit FDF71VD Outdoor unit FDC71VNX
Power source 220-240V
~
50Hz / 220V
~
60Hz
Operation data Cooling Heating
Nominal capacity kW
7.1 [ 3.2 (Min.)
~
8.0 (Max.)]
8.0 [ 3.6 (Min.)
~
9.0 (Max.)]
Power consumption kW 2.21 2.21
Running current A 9.8 / 10.3 9.9 / 10.4
Power factor ％ 98 97
Inrush current A 5 < Max.running current 17 >
Sound Pressure Level dB(A)
P-Hi : 42 Hi : 39 Me : 35 Lo : 33
Cooling : 51, Heating : 48
Exterior dimensions
Height × Width × Depth
Exterior appearance Ceramic White Stucco White
(Munsell color) (N8.0) near equivalent (4.2Y7.5/1.1 ) near equivalent
Net weight
kg
49 60
Refrigerant equipment
Compressor type & Q'ty
— RMT5118MDE2 × 1
Starting method — Direct line start
Refrigerant oil — 0.675 M-MA68
Heat exchanger
Louver fine & inner grooved tubing
M shape fin & inner grooved tubing
Refrigerant control — Electronic expansion valve
Air handling equipment
Fan type & Q'ty
Centrifugal fan × 1 Propeller fan × 1
Motor <Starting method> W 157 < Direct line start > 86 < Direct line start >
Air flow (Standard) CMM
P-Hi : 20 Hi : 18 Me : 16 Lo : 14
Cooling : 60, Heating : 50
External static pressure Pa 0
Outside air intake Not possible —
0
Air filter, Q'ty Plastic net × 1 (Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for Compressor )
Insulation (noise & heat) Polyurethane form —
Electric heater W — 20 (Crank case heater)
Remote controller RC-E5 Installed / wireless : RCN-KIT3-E (option)
Room temperature control Thermostat by electronics —
Safety equipment
Overload protection for fan motor Internal thermostat for fan motor
Frost protection thermostat
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size
Connecting method Flare piping Flare piping
Refrigerant line (one way) length Max.50m
Vertical height difference between
outdoor unit and indoor unit
Max.30m (Outdoor unit is higher)
Max.15m (Outdoor unit is lower)
Refrigerant Quantity
R410A 2.95kg in outdoor unit (incl. the amount for the piping of : 30m)
Drain pump — —
Drain Hose Connectable with VP20
Insulation for piping Necessary (both Liquid & Gas lines)
Standard Accessories Mounting kit —
Notes (1) The data are measured at the following conditions.
Model
Item
mm
mm
See page 152
1,850 × 600 × 320 750 × 880 (+88) × 340
Holes size φ20 × 3pcs
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber. During operation
these value are somewhat higher due to ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 230V50Hz or 220V60Hz.
(5) If wireless remote controller is used, only 3-speed fan setting (Hi-Me-Lo) is available.
Indoor air temperature
Operation DB
27
o
C
20
o
C 7
o
C 6
o
C
19
o
C 35
o
C 24
o
C
WB DB WB
Cooling
Heating
Item
Outdoor air temperature
Liquid line : I/Uφ9.52 (3/8") Pipeφ9.52 (3/8") × 0.8 O/U 9.52 (3/8")
Gas line
: φ 15.88 (5/8") φ15.88 (5/8") × 1.0 φ15.88 (5/8")
IP code IPXO IP24
