–4–
Name of each part and its function
INDOOR UNIT
OUTDOOR UNIT
Air outlet
Air inlet
(On side & rear surface)
Outdoor unit fan
Heat exchanger
Air filter
Removes dust or dirt from the inlet air.
Air Inlet panel
Draws the indoor air.
Drain hose
Drains water from the indoor unit.
Left/right airflow direction adjustment louver
Page 12
Up/down airflow direction adjustment flap
Page 12
Air outlet
Air blows out of here.
Heat exchanger
Room temperature sensor
Air-cleaning filter
Refrigerant piping connection and electric wire
Indoor unit fan
Page 25
Page 24
Page 24
RLA012A021B_EN_001-030 7/25/13, 15:424
To Next Page
