5.12 Standard Timer Function Blocks
5.12.1 Pulse timer
5-205
5
APPLICATION FUNCTIONS
TP(_E), TP_HIGH(_E)
TP(_E), TP_HIGH(_E)
5.12 Standard Timer Function Blocks
5.12.1 Pulse timer
TP(_E), TP_HIGH(_E)
Function
Operation processing
Turns ON for the duration set to after is turned ON. The duration (elapsed time) during
which stays ON is set to .
When the elapsed time reaches the preset time, turns OFF.
The elapsed time is not reset even when turns OFF. It is reset and turns ON again when
is turned from OFF to ON next.
TP(_E), TP_HIGH(_E)
_E: With EN/ENO
indicates any of the following
functions.
TP TP_E
TP_HIGH TP_HIGH_E
Input argument, EN:
Executing condition (TRUE: Execution, FALSE: Stop) :Bit
s:
Input :Bit
n:
Output time setting value :Time
Output argument, ENO:
Output status (TRUE: Normal, FALSE: Error or stop) :Bit
d1:
Output :Bit
d2:
Elapsed time :Time
Universal
UD
High
Performance
Structured ladder
TP_HIGH_E
EN ENO
s
n
d1
d2
ST
TP_HIGH_E
(EN, s, n, d1, d2);ENO:=
d1
n
s
d1
d2
d1
d1 d1
s
