TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS
TSB Revision
WHEEL AND TIRE
31-18
DIAGNOSTIC TROUBLE CODE CHART
M1311002700132
During diagnosis, a DTC associated with another system may be set when the ignition switch
(engine starting switch) is turned to the "ON" position with connector(s) disconnected. When
diagnosis is finished, check all systems for DTC(s). If DTC(s) are set, erase them all.
Tire pressure sensor ID registration must not be done before any diagnosis.
DTC Diagnostic item Reference page
C1564 Vehicles speed data invalid
P.31-19
C1900 Tire ID code No registration
P.31-20
C1901 Vehicles speed signal
P.31-22
C1902 Reset fail (warning threshold)
P.31-23
C1910 Transmitter BATT. voltage, Tire1
P.31-26
C1911 Tire ID reception fail, Tire1
C1912 Tire air pressure low, Tire1
P.31-28
C1913 Acceleration sensor, Tire1
P.31-30
C1914 Tire air pressure sensor, Tire1
C1915 Transmitter OFF mode, Tire1
P.31-32
C1916 Temperature sensor, Tire1
P.31-30
C1920 Transmitter BATT. voltage, Tire2
P.31-26
C1921 Tire ID reception fail, Tire2
C1922 Tire air pressure low, Tire2
P.31-28
C1923 Acceleration sensor, Tire2
P.31-30
C1924 Tire air pressure sensor, Tire2
C1925 Transmitter OFF mode, Tire2
P.31-32
C1926 Temperature sensor, Tire2
P.31-30
C1930 Transmitter BATT. voltage, Tire3
P.31-26
C1931 Tire ID reception fail, Tire3
C1932 Tire air pressure low, Tire3
P.31-28
C1933 Acceleration sensor, Tire3
P.31-30
C1934 Tire air pressure sensor, Tire3
C1935 Transmitter OFF mode, Tire3
P.31-32
C1936 Temperature sensor, Tire3
P.31-30
C1940 Transmitter BATT. voltage, Tire4
P.31-26
C1941 Tire ID reception fail, Tire4
C1942 Tire air pressure low, Tire4
P.31-28
C1943 Acceleration sensor, Tire4
P.31-30
C1944 Tire air pressure sensor, Tire4
C1945 Transmitter OFF mode, Tire4
P.31-32
C1946 Temperature sensor, Tire4
P.31-30
