TIRE PRESSURE MONITORING SYSTEM (TPMS)
TSB Revision
WHEEL AND TIRE
31-47
TPMS TRANSMITTER
REMOVAL AND INSTALLATION
M1311003800154
Certain components of this vehicles, such as TPMS transmitters, may contain perchlorate
materials. Special handling may apply. For additional information, see www.dtsc.ca.gov/haz
-
ardouswaste/perchlorate.
Ensure valve cap is always in place except when adjusting tire pressure.
If the valve core and valve cap are replaced, use a genuine replacement part. The valve core is
similar to a conventional one, but uses nickel plating to avoid corrosion.
Replace the valve with a new one every five years or when the tire is replaced.
Do not drop the TPMS transmitter from height greater than 1 meter (3.3 feet).
Do not expose the TPMS transmitter to extraneous magnetic fields.
TPMS transmitter should not be stored at temperatures above 80C (176F).
TPMS transmitter should not be exposed to temperatures above 100C (212F).
If the TPMS transmitter is replaced, execute "Tire Pressure Sensor ID Registration" on scan tool
MB991958 "Special Function."
Be careful not to damage the TPMS transmitter.
Pre-removal Operation
Wheel and Tire Removal
Post-installation Operation
Wheel and Tire Installation
Tire Pressure Sensor ID Registration If a new TPMS
transmitter is installed (Refer to
P.31-42).
After the tire pressure sensor ID registration, check that
the TPMS warning light does not illuminate or flash.
