ABS <4WD> -
Troubleshooting
35B-11
<Vehicles without rear differential lock system>
Code No. 26 Center differential lock switch system
Probable cause
Code No. 27 Rear differential lock switch system
The ABS-ECU is designed to accommodate the fitting of a rear differential lock.
Because of this, for vehicles which are not equipped with a rear differential lock,
system voltage is applied to terminal (33) of the ABS-ECU instead of the rear
differential lock switch signal. If there is an open circuit in the lines by which this
system voltage is applied, the ABS-ECU outputs code Nos. 26 and 27.
D
Malfunction of harness or connector
D
Malfunction of the ABS-ECU
NG
OK
Replace the ABS-ECU.
NG
Check the harness wire, and repair if necessary.
D
Between the ignition switch and the ABS-ECU
OK
NG
Repair
Measure at ABS-ECU connector E-107.
D
Disconnect the connector and measure at the harness
side.
D
Ignition switch: ON
D
Voltage between terminal 33 and body earth
OK:
System voltage
Check the trouble symptoms.
Check the following connector:
D-32, D-124, D-208, D-210,
E-13, E-107, F-17
OK NG
Repair
NG
Check the trouble symptoms.
Check the following connector:
E-107
