AP-5131 Access Point: Installation Guide
8
The 5.2 GHz antenna suite includes the following models:
For detailed specifications on the antennas available to the AP-5131, refer to the AP-51xx Product
Reference Guide. Appendix A of that document contains detailed AP-5131 antenna specifications and
their instructions for optimal use. The guide is available on the Motorola Web site, at
http://support.symbol.com/support/product/manuals.do
.
3.3.2 Power Injector System
The AP-5131 can receive power either directly form a Motorola 48V AC-DC power supply
(Part No. 50-14000-243R) or via an Ethernet cable connected to the LAN port (using the 802.3af
standard).
When users purchase a Motorola WLAN solution, they often need to place access points in obscure
locations. In the past, a dedicated power source was required for each access point in addition to the
Ethernet infrastructure. This often required an electrical contractor to install power drops at each
access point location. An approved power injector solution merges power and Ethernet into one
cable, reducing the burden of installation and allows optimal AP-5131 placement in respect to the
intended radio coverage area.
The Power Injector is included in certain AP-5131 kits. The Power Injector
(Part No. AP-PSBIAS-1P2-AFR) is an integrated AC-DC converter and 802.3af power injector which
requires 110-220V AC power to combine low-voltage DC with Ethernet data in a single cable
connecting to the AP-5131.
The Motorola AP-5131 Power Supply (Part No. 50-14000-243R) is not included in the kit and is
orderable separately as an accessory.
Part Number Antenna Type Nominal Net Gain (dBi)
ML-5299-WPNA1-01R Panel Antenna 13.0
ML-5299-HPA1-01R Wide-Band Omni-Directional
Antenna
5.0
ML-2452-APA2-01 Dual-Band 4.0
CAUTION The AP-5131 supports any standards-based 802.3af compliant power
source (including non-Motorola power sources). However, using the
wrong solution (including a POE system used on a legacy Motorola
access point) could severely damage the AP-5131 and void the
product warranty.
!
72-70931_01.book Page 8 Monday, May 4, 2009 8:10 AM
