22 AP 7161 Access Point
1.11.2 Three Radio LEDs
A three radio model Access Point with sensor (P/N AP-7161-66S40-US and AP-7161-66S40-WR) has the following
unique LED behavior:
LED 1
(Sensor)
LED 2
(2.4 GHz)
LED 3
(5 GHz)
LED 4
(GE2/WAN)
LED 5
(GE1/LAN)
LED 6
(System)
Blinking
Emerald
and
Amber at 2
second interval
indicates a radio
is present but
not connected to
a server.
Solid
Amber
indicates a radio
is present and
connected to a
server.
Blinking
Emerald
indicates
802.11b/g/n
activity.
Solid
Emerald
indicates a radio
is present but
not configured.
Blinking
Amber
indicates
802.11a/n
activity.
Solid
Amber
indicates a radio
is present but
not configured.
LED
Off
indicates the
port is not
connected.
Blinking
Green
indicates
normal
operation.
Rapidly blinking
Yellow
indicates a port
error.
LED
Off
indicates the
port is not
connected.
Blinking
Green
indicates
normal
operation.
Rapidly blinking
Yellow
indicates a port
error.
Solid
Red
indicates
diagnostic mode.
Blinking
Red at
1 second interval
indicates POST
failure.
Solid
White
following
diagnostic
mode
indicates
booting.
Blinking
Red and
White at 1
second interval
indicates “no
adoption”.
Solid
White
indicates normal
operation.
