Motorola CM360 Service Information

VHF1 1-25W PCB 8486672Z01 / Schematics 4-19
2.1 VHF1 PCB 8486672Z01 Parts List 1-25W
Circuit
Ref.
Motorola
Part No.
Description
C1000 2113740F59 CAP CHIP REEL CL1 +/-30 220
C1001 2311049A08 KEMET CAPS
C1002 2111078B59 CHIP CAP RF 470 5 NPO 100V
C1003 2111078B59 CHIP CAP RF 470 5 NPO 100V
C1004 2111078B49 CAP CHIP RF 180 5 NPO 100V
C1005 2111078B51 CAP CHIP RF 220 5 NPO 100V
C1006 2111078B47 CAP CHIP RF 150 5 NPO 100V
C1007 NOT PLACED GCAM DUMMY PART NUMBER
C1008 2111078B45 CAP CHIP RF 130 5 NPO 100V
C1009 2111078B45 CAP CHIP RF 130 5 NPO 100V
C1010 2111078B45 CAP CHIP RF 130 5 NPO 100V
C1011 2111078B38 CAP CHIP RF 68 5 NPO 100V
C1012 2111078B36 CAP CHIP RF 56 5 NPO 100V
C1013 2111078B36 CAP CHIP RF 56 5 NPO 100V
C1014 NOT PLACED GCAM DUMMY PART NUMBER
C1015 2111078B34 CAP CHIP RF 47 5 NPO 100V
C1016 2111078B31 CAP CHIP RF 36 5 NPO 100V
C1017 2111078B27 CAP CHIP RF 30 5 NPO 100V
C1018 NOT PLACED GCAM DUMMY PART NUMBER
C1019 2111078B21 CAP CHIP RF 20 5 NPO 100V
C1020 2111078B15 CAP CHIP RF 12 5 NPO 100V
C1021 2111078B13 CAP ALT E16
C1022 2111078B09 CAP ALT E17
C1023 2111078B21 CAP ALT E35
C1024 2111078B03 CAP CHIP RF 3.9.25 NPO 100V
C1025 2111078B07 CAP CHIP RF 5.6.25 NPO 100V
C1027 2311049A45 CAP TANT CHIP 10 10 35
C1028 2113743K15 CER CHIP CAP .100UF
C1029 2113743K15 CER CHIP CAP .100UF
C1030 2113743E07 CER CHIP CAP .022UF
C1031 2113743E07 CER CHIP CAP .022UF
C1032 2113743E07 CER CHIP CAP .022UF
C1033 2113743E07 CER CHIP CAP .022UF
C1034 2113740F59 CAP CHIP REEL CL1 +/-30 220
C1035 2113743E07 CER CHIP CAP .022UF
C1036 2113743E07 CER CHIP CAP .022UF
C1037 2113743E07 CER CHIP CAP .022UF
C1038 NOT PLACED GCAM DUMMY PART NUMBER
C1039 2113743E07 CER CHIP CAP .022UF
C1040 2113741F33 CAP CHIP CL2 X7R REEL 2200
C1041 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1042 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1043 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1044 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1045 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1046 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1047 2113743K17 CAP CHIP .330 UF +80-20% 16V
C1048 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1049 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1050 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1051 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1052 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1053 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1054 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1055 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1056 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1057 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1058 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1059 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1060 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1061 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1062 2113741F25 CAP CHIP CL2 X7R REEL 1000
Circuit
Ref.
Motorola
Part No.
Description
C1063 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1064 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1065 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1066 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1067 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1068 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1069 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1070 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1071 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1072 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1073 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1074 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1075 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1076 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1077 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1078 2113740F59 CAP CHIP REEL CL1 +/-30 220
C1079 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1080 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1081 NOT PLACED GCAM DUMMY PART NUMBER
C1082 NOT PLACED GCAM DUMMY PART NUMBER
C1083 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1084 2113740F59 CAP CHIP REEL CL1 +/-30 220
C1085 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1086 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1087 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1088 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1089 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1090 NOT PLACED GCAM DUMMY PART NUMBER
C1091 NOT PLACED GCAM DUMMY PART NUMBER
C1092 NOT PLACED GCAM DUMMY PART NUMBER
C1093 NOT PLACED GCAM DUMMY PART NUMBER
C1094 NOT PLACED GCAM DUMMY PART NUMBER
Circuit
Ref.
Motorola
Part No.
Description
C1095 NOT PLACED GCAM DUMMY PART NUMBER
C1097 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1098 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1099 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1100 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1101 2113740F51 CAP CHIP REEL CL1 +/-30 100
C1102 2113740F51 CAP CHIP REEL CL1 +/-30 100
C1103 2113741A57 CAP CHIP 33K +-5%
(2160521A31)
C1104 2113741A53 CAP CHIP CL2 X7R REEL 22000
C1105 2113740F67 CAP CHIP CL1 +/-30 470 5%
C1106 2113740F67 CAP CHIP CL1 +/-30 470 5%
C1107 2113740F67 CAP CHIP CL1 +/-30 470 5%
C1108 2113740F69 CAP CHIP REEL CL1 +/-30 560
C1109 2113740F59 CAP CHIP REEL CL1 +/-30 220
C1110 2113740F59 CAP CHIP REEL CL1 +/-30 220
C1112 2113740F59 CAP CHIP REEL CL1 +/-30 220
C1113 2113740F59 CAP CHIP REEL CL1 +/-30 220
C1114 2113740F59 CAP CHIP REEL CL1 +/-30 220
C1115 2113740F59 CAP CHIP REEL CL1 +/-30 220
C1116 2113740F59 CAP CHIP REEL CL1 +/-30 220
C1117 2113740F43 CAP CHIP REEL CL1 +/-30 47
C1118 2113740F39 CAP CHIP REEL CL1 +/-30 33
C1119 2113740F39 CAP CHIP REEL CL1 +/-30 33
C1120 2113740F39 CAP CHIP REEL CL1 +/-30 33
C1121 2113740F35 CAP CHIP REEL CL1 +/-30 22
C1122 2113740F59 CAP CHIP REEL CL1 +/-30 220
C1123 2113740F59 CAP CHIP REEL CL1 +/-30 220
C1124 2113740F59 CAP CHIP REEL CL1 +/-30 220
C1125 2113740F59 CAP CHIP REEL CL1 +/-30 220
C1126 2113740F59 CAP CHIP REEL CL1 +/-30 220
C1127 2360567A03 CAP TANTALUM
Circuit
Ref.
Motorola
Part No.
Description
