VHF PCB 8486062B14 Parts List 4-27
7.0 VHF PCB 8486062B14 Parts List
Circuit
Ref
Motorola
Part No
Description
B501 0986237A02 CONN, CONTACT BATT
B503 3980502Z01 CONTACT, BACKUP B+
only GP360, GP380, GP680
B504 3980501Z01 CONTACT, BACKUP B-
only GP360, GP380, GP680
C3200 2113743N31 16.0 PF 5% COG
C3203 2113743N50 100 PF 5% COG
C3204 2113743L41 10000 PF 10%
C3205 2113928N01 CER CHIP 0.1UF 10% 6.3
C3206 2113743L41 10000 PF 10%
C3207 2113743N10 2.2 PF +-.25PF COG
C3209 2311049A07 TANT 10% 1.0UF
C3210 2113743L17 1000 PF 10%
C3211 2311049A56 TAN CHIP A/P 4.7 20 10
C3212 2311049A07 TANT 10% 1.0UF
C3213 2311049A56 TAN CHIP A/P 4.7 20 10
C3214 2113928N01 CER CHIP 0.1UF 10% 6.3
C3215 2113743N26 10.0 PF 5% COG
C3218 2311049A56 TAN CHIP A/P 4.7 20 10
C3219 2113928N01 CER CHIP 0.1UF 10% 6.3
C3220 2113743N26 10.0 PF 5% COG
C3221 2113743L41 10000 PF 10%
C3222 2113928N01 CER CHIP 0.1UF 10% 6.3
C3223 2113928N01 CER CHIP 0.1UF 10% 6.3
C3224 2113928N01 CER CHIP 0.1UF 10% 6.3
C3225 2113928N01 CER CHIP 0.1UF 10% 6.3
C3226 2113928N01 CER CHIP 0.1UF 10% 6.3
C3227 2113743L41 10000 PF 10%
C3228 2113743L41 10000 PF 10%
C3229 2113743N50 100 PF 5% COG
C3230 2113740F51 REEL CL1 +/-30 100
C3231 2180478Z20 MONOLITHIC CERAMIC (1.0UF)
C3232 2180478Z20 MONOLITHIC CERAMIC (1.0UF)
C3233 2180478Z20 MONOLITHIC CERAMIC (1.0UF)
C3234 2180478Z20 MONOLITHIC CERAMIC (1.0UF)
C3235 2113743A23 .220UF 10%
C3238 2113743A24 .330 UF 10% 16V
C3239 2113743E07 CER CHIP .022UF
C3240 2113743A23 .220UF 10%
C3241 2113743L19 1200 PF 10%
C3242 2109720D14 CER CHIP LOW DIST 0.1UF
C3243 2113743E07 CER CHIP .022UF
C3244 2113743L41 10000 PF 10%
C3270 2113743E07 CER CHIP .022UF
C3271 2113743L05 330 PF 10%
C3272 2113743N18 4.7 PF +-.25PF COG
C3273 2113743N26 10.0 PF 5% COG
C3274 2113743N38 33.0 PF 5% COG
C3275 2113743N44 56.0 PF 5% COG
C3276 2113743N42 47.0 PF 5% COG
C3277 2113743N48 82.0 PF 5% COG
C3278 2113743E07 CER CHIP .022UF
C3279 2311049A40 GLOBAL TANT 10% 2.2 UF
C3280 2113743L41 10000 PF 10%
C3301 2113743N20 5.6 PF +-.5PF COG
C3302 2113743N54 150 PF 5% COG
C3303 2113743N30 15.0PF 5% COG
C3304 2113743N54 150 PF 5% COG
C3306 2113928N01 CER CHIP 0.1UF 10% 6.3
C3307 2113743N50 100 PF 5% COG
C3308 2113743L05 330 PF 10%
C3309 2113928N01 CER CHIP 0.1UF 10% 6.3
C3311 2113743N54 150 PF 5% COG
C3312 2113743N31 16.0 PF 5% COG
C3313 2113743N54 150 PF 5% COG
C3315 2113743N26 10.0 PF 5% COG
C3316 2113743N14 3.3 PF +-.25PF COG
C3317 2113743N40 39.0 PF 5% COG
C3318 2113743M08 22000PF +80-20% Y5V
C3320 2113743N48 82.0 PF 5% COG
C3321 2113743L05 330 PF 10%
C3322 2113743N50 100 PF 5% COG
C3323 2113743N50 100 PF 5% COG
C3324 2113743N38 33.0 PF 5% COG
C3325 2113743L17 1000 PF 10%
C3327 2113743L05 330 PF 10%
C3329 2113743L05 330 PF 10%
C3330 2113743N50 100 PF 5% COG
C3331 2113743N50 100 PF 5% COG
C3332 2113743N40 39.0 PF 5% COG
C3334 2113743N33 20.0 PF 5% COG
C3335 2113743N34 22.0 PF 5% COG
C3336 2311049A18 TANT 10% 10UF
C3337 2113743M08 22000PF +80-20% Y5V
C3338 2113743L09 470 PF 10%
C3339 2113743N26 10.0 PF 5% COG
C3501 2113743L05 330 PF 10%
C3502 2113743N38 33.0 PF 5% COG
C3503 2113743N38 33.0 PF 5% COG
C3504 2113743M08 22000PF +80-20% Y5V
C3505 2113743N38 33.0 PF 5% COG
C3508 2113743M08 22000PF +80-20% Y5V
C3509 2113743L05 330 PF 10%
C3512 2113740F43 REEL CL1 +/-30 47
C3513 2113740F38 REEL CL1 +/-30 30
C3514 2113740F67 CL1 +/-30 470 5%
C3515 2113743L29 3300PF 10%
C3516 2311049A08 KEMET CAPS
C3517 2113740F51 REEL CL1 +/-30 100
C3518 2113740F63 CL1 +/-30 330 5%
C3519 2113740F35 REEL CL1 +/-30 22
C3521 2111078B51 RF 220 5 NPO 100V
C3523 2111078B44 RF 120 5 NPO 100V
C3524 2113740F33 REEL CL1 +/-30 18
C3525 2113740F27 REEL CL1 +/-30 10
C3526 2113743M08 22000PF +80-20% Y5V
C3528 2113740F26 REEL CL1 +/-30 9.1
C3531 2113740F34 REEL CL1 +/-30 20
C3532 2113740F47 REEL CL1 +/-30 68
Circuit
Ref
Motorola
Part No
Description
C3533 2113740F24 REEL CL1+/-30 7.5
C3534 2113740F19 CHIP CAP, CER 4.7PF
C3535 2113740F37 REEL CL1+/-30 27
C3536 2113740F31 REEL CL1 +/-30 15
C3537 2113740F33 REEL CL1 +/-30 18
C3539 2113740F21 REEL CL1+/-30 5.6
C3541 2113743M08 22000PF +80-20% Y5V
C3542 2113743L05 330 PF 10%
C3543 2113743M08 22000PF +80-20% Y5V
C3544 2113743L05 330 PF 10%
C3546 2113743L05 330 PF 10%
C3547 2113743M08 22000PF +80-20% Y5V
C3550 2113743N23 7.5 PF +-.5PF COG
C3551 2113743N46 68.0 PF 5% COG
C3552 2113743N44 56.0 PF 5% COG
C3560 2311049A07 TANT 10% 1.0UF
C3561 2113743M08 22000PF +80-20% Y5V
C3562 2113743L29 3300PF 10%
C3563 2113743L29 3300PF 10%
C3564 2113743L01 220 PF 10%
C3565 2113743E07 CER CHIP .022UF
C3566 2113743N50 100 PF 5% COG
C3567 2113743L05 330 PF 10%
C3568 2113743L29 3300PF 10%
C3569 2113743M08 22000PF +80-20% Y5V
C3570 2113743L05 330 PF 10%
C3571 2113743L09 470 PF 10%
C3701 2113743L41 10000 PF 10%
C3702 2113743L41 10000 PF 10%
C3703 2113743L41 10000 PF 10%
C3704 2113743L41 10000 PF 10%
C3705 2113743E20 CHIP. 10 UF 10%
C3706 2311049J11 CAPACITOR TANT 10% 4.7UF
C3707 2113743N34 22.0 PF 5% COG
C3708 2113743M24 100000 PF +80-20% Y5V
C3709 2113743M24 100000 PF +80-20% Y5V
C3710 2104993J02 MONOLITHIC CERAMIC (2.2UF)
C3711 2311049A69 TAN CHIP 10.0 UF 20% 6.3V
C3712 2113743M24 100000 PF +80-20% Y5V
C3713 2311049A09 TANT 2.2 UF 10%
C3714 2311049J11 CAPACITOR TANT 10% 4.7UF
C3715 2113743L09 470 PF 10%
C3721 2113743E20 CHIP. 10 UF 10%
C3722 2113743E20 CHIP. 10 UF 10%
C3724 2311049A08 KEMET CAPS
C3726 2113743N24 8.2 PF + -.5PF COG
C3727 2113743N50 100 PF 5% COG
C3731 2113743L41 10000 PF 10%
C3732 2113743L41 10000 PF 10%
C3733 2104993J02 MONOLITHIC CERAMIC (2.2UF)
C3734 2113743L41 10000 PF 10%
C3742 2113743L01 220 PF 10%
C3743 2113743L01 220 PF 10%
C3744 2113743L01 220 PF 10%
C3745 2113743L01 220 PF 10%
C3746 2113743L01 220 PF 10%
Circuit
Ref
Motorola
Part No
Description
C3752 2113743L17 1000 PF 10%
C3753 2311049A56 TAN CHIP A/P 4.7 20 10
C3754 2113743M24 100000 PF +80-20% Y5V
C3755 2104993J02 MONOLITHIC CERAMIC (2.2UF)
* C3761 2113743N44 56.0 PF 5% COG
* C3762 2113740F63 CL1 +/-30 330 5%
* C3763 2113743N08 1.6 PF +-.25PF COG
C3801 2113743N18 4.7 PF +-.25PF COG
C3803 2113743L17 1000 PF 10%
C3804 2113743E20 CHIP. 10 UF 10%
C3805 2113743N18 4.7 PF +-.25PF COG
C3806 2113743N50 100 PF 5% COG
C3808 2113743N30 15.0PF 5% COG
C3809 2113743N36 27.0 PF 5% COG
C3811 2113743M24 100000 PF +80-20% Y5V
C3812 2113743M24 100000 PF +80-20% Y5V
C3813 2113743L41 10000 PF 10%
C3815 2113743L17 1000 PF 10%
C3816 2113743N22 6.8 PF +-.5PF COG
C3818 2113743E07 CER CHIP .022UF
C3821 2113743L41 10000 PF 10%
C3822 2113743L17 1000 PF 10%
C3823 2113743L41 10000 PF 10%
C3824 2113743N44 56.0 PF 5% COG
C3825 2113743N30 15.0PF 5% COG
C3826 2113743N18 4.7 PF +-.25PF COG
C3827 2113743E07 CER CHIP .022UF
C3828 2109720D01 CER CHIP LOW DIS T .01UF
C3829 2109720D01 CER CHIP LOW DIS T .01UF
C3830 2113743N46 68.0 PF 5% COG
C3832 2113743L17 1000 PF 10%
C3833 2113743N18 4.7 PF +-.25PF COG
C3834 2113743N44 56.0 PF 5% COG
C3835 2113743N22 6.8 PF +-.5PF COG
C3836 2113743N30 15.0PF 5% COG
C3842 2113743L17 1000 PF 10%
C400 2113743L41 10000 PF 10%
C401 2113743M24 100000 PF +80-20% Y5V
C402 2113743M24 100000 PF +80-20% Y5V
C403 2113928D08 CERAMIC CHIP 10.0UF
C407 2113928N01 CER CHIP 0.1UF 10% 6.3
C408 2113743N50 100 PF 5% COG
C409 2113743M24 100000 PF +80-20% Y5V
C410 2113928N01 CER CHIP 0.1UF 10% 6.3
C411 2113743M24 100000 PF +80-20% Y5V
C414 2113743M24 100000 PF +80-20% Y5V
C415 2109720D01 CER CHIP LOW DIS T .01UF
C416 2113928N01 CER CHIP 0.1UF 10% 6.3
C419 2113743L41 10000 PF 10%
C420 2113743L41 10000 PF 10%
C421 2113928N01 CER CHIP 0.1UF 10% 6.3
C422 2113743M24 100000 PF +80-20% Y5V
C423 2113743N50 100 PF 5% COG
C424 2311049A59 TANT CHIP A/P 10UF 10% 6V
C425 2113743M24 100000 PF +80-20% Y5V
C426 2113743N50 100 PF 5% COG
Circuit
Ref
Motorola
Part No
Description
To Next Page
