VHF PCB 8486101B10 Parts List (GP1280) 4-33

9.0 VHF PCB 8486101B10 Parts List

(GP1280)

Circuit

Ref

Motorola

Part No

Description

B501 0986237A01 CONN, CONTACT BATTERY

B503 3980502Z01 CONTACT, BACKUP B+

B504 3980501Z01 CONTACT, BACKUP B-

C3200 2113743N31 16.0 PF 5%

C3203 2113743N50 100 PF 5%

C3204 2113743L41 10000 PF 10%

C3205 2113928N01 0.1UF 10% 6.3

C3206 2113743L41 10000 PF 10%

C3207 2113743N10 2.2 PF +-.25PF

C3209 2311049A07 TANT 10% 1.0UF

C3210 2113743L17 1000 PF 10%

C3211 2311049A56 TAN CHIP A/P 4.7 20 10

C3212 2311049A07 TANT 10% 1.0UF

C3213 2311049A56 TAN CHIP A/P 4.7 20 10

C3214 2113928N01 CERAMIC CHIP 10.0UF

C3215 2113743N26 10.0 PF 5%

C3218 2311049A56 TAN CHIP A/P 4.7 20 10

C3219 2113928N01 CERAMIC CHIP 10.0UF

C3220 2113743N26 10.0 PF 5%

C3221 2113743L41 10000 PF 10%

C3222 2113928N01 CERAMIC CHIP 10.0UF

C3223 2113928N01 0.1UF 10% 6.3

C3224 2113928N01 0.1UF 10% 6.3

C3225 2113928N01 0.1UF 10% 6.3

C3226 2113928N01 0.1UF 10% 6.3

C3227 2113743L41 10000 PF 10%

C3228 2113743L41 10000 PF 10%

C3229 2113743N50 100 PF 5%

C3230 2113740F51 REEL CL1 +/-30 100

C3231 2180478Z20 MONOLITH CERAMIC (1.0UF)

C3232 2180478Z20 MONOLITH CERAMIC (1.0UF)

C3233 2180478Z20 MONOLITH CERAMIC (1.0UF)

C3234 2180478Z20 MONOLITH CERAMIC (1.0UF)

C3235 2113743A23 .220UF 10%

C3238 2113743A24 .330 UF 10% 16V

C3239 2113743E07 .022UF

C3240 2113743A23 .220UF 10%

C3241 2113743L19 1200 PF 10%

C3242 2109720D14 LOW DIST 0.1UF

C3243 2113743E07 .022UF

C3244 2113743L41 10000 PF 10%

C3270 2113743E07 .022UF

C3271 2113743L05 330 PF 10%

C3272 2113743N18 4.7 PF +-.25PF

C3273 2113743N26 10.0 PF 5%

C3274 2113743N38 33.0 PF 5%

C3275 2113743N44 56.0 PF 5%

C3276 2113743N42 47.0 PF 5%

C3277 2113743N48 82.0 PF 5%

C3278 2113743E07 .022UF

C3279 2311049A40 GLOBAL TANT 10% 2.2 UF

C3280 2113743L41 10000 PF 10%

C3301 2113743N20 5.6 PF +-.5PF

C3302 2113743N54 150 PF 5%

C3303 2113743N30 15.0PF 5%

C3304 2113743N54 150 PF 5%

C3306 2113928N01 0.1UF 10% 6.3

C3307 2113743N50 100 PF 5%

C3308 2113743L05 330 PF 10%

C3309 2113928N01 0.1UF 10% 6.3

C3311 2113743N54 150 PF 5%

C3312 2113743N31 16.0 PF 5%

C3313 2113743N54 150 PF 5%

C3315 2113743N26 10.0 PF 5%

C3316 2113743N14 3.3 PF +-.25PF

C3317 2113743N40 39.0 PF 5%

C3318 2113743M08 22000PF +80-20% Y5V

C3320 2113743N48 82.0 PF 5%

C3321 2113743L05 330 PF 10%

C3322 2113743N50 100 PF 5%

C3323 2113743N50 100 PF 5%

C3324 2113743N38 33.0 PF 5%

C3325 2113743L17 1000 PF 10%

C3327 2113743L05 330 PF 10%

C3329 2113743L05 330 PF 10%

C3330 2113743N50 100 PF 5%

C3331 2113743N50 100 PF 5%

C3332 2113743N40 39.0 PF 5%

C3334 2113743N33 20.0 PF 5%

C3335 2113743N34 22.0 PF 5%

C3336 2311049A18 CAP. TANT 10% 10UF

C3337 2113743M08 22000PF +80-20% Y5V

C3338 2113743L09 470 PF 10%

C3339 2113743N26 10.0 PF 5%

C3501 2113743L05 330 PF 10%

C3502 2113743N38 33.0 PF 5%

C3503 2113743N38 33.0 PF 5%

C3504 2113743M08 22000PF +80-20% Y5V

C3505 2113743N38 33.0 PF 5%

C3508 2113743M08 22000PF +80-20% Y5V

C3509 2113743L05 330 PF 10%

C3512 2113740F43 REEL CL1 +/-30 47

C3513 2113740F38 REEL CL1 +/-30 30

C3514 2113740F67 CL1 +/-30 470 5%

C3515 2113743L29 3300PF 10%

C3516 2311049A08 KEMET CAPS

C3517 2113740F51 REEL CL1 +/-30 100

C3518 2113740F63 CL1 +/-30 330 5%

Circuit

Ref

Motorola

Part No

Description

C3519 2113740F35 REEL CL1 +/-30 22

C3521 2111078B51 RF 220 5 NPO 100V

C3523 2111078B44 RF 120 5 NPO 100V

C3524 2113740F33 REEL CL1 +/-30 18

C3525 2113740F27 REEL CL1 +/-30 10

C3526 2113743M08 22000PF +80-20% Y5V

C3528 2113740F26 REEL CL1 +/-30 9.1

C3531 2113740F34 REEL CL1 +/-30 20

C3532 2113740F47 REEL CL1 +/-30 68

C3533 2113740F24 REEL CL1+/-30 7.5

C3534 2113740F19 CHIP CAP, CER 4.7PF

C3535 2113740F37 REEL CL1+/-30 27

C3536 2113740F31 REEL CL1 +/-30 15

C3537 2113740F33 REEL CL1 +/-30 18

C3539 2113740F21 REEL CL1+/-30 5.6

C3541 2113743M08 22000PF +80-20% Y5V

C3542 2113743L05 330 PF 10%

C3543 2113743M08 22000PF +80-20% Y5V

C3544 2113743L05 330 PF 10%

C3546 2113743L05 330 PF 10%

C3547 2113743M08 22000PF +80-20% Y5V

C3550 2113743N23 7.5 PF +-.5PF

C3551 2113743N46 68.0 PF 5%

C3552 2113743N44 56.0 PF 5%

C3560 2311049A07 TANT 10% 1.0UF

C3561 2113743M08 22000PF +80-20% Y5V

C3562 2113743L29 3300PF 10%

C3563 2113743L29 3300PF 10%

C3564 2113743L01 220 PF 10%

C3565 2113743E07 .022UF

C3566 2113743N50 100 PF 5%

C3567 2113743L05 330 PF 10%

C3568 2113743L29 3300PF 10%

C3569 2113743M08 22000PF +80-20% Y5V

C3570 2113743L05 330 PF 10%

C3571 2113743L09 470 PF 10%

C3701 2113743L41 10000 PF 10%

C3702 2113743L41 10000 PF 10%

C3703 2113743L41 10000 PF 10%

C3704 2113743L41 10000 PF 10%

C3705 2113743E20 CHIP. 10 UF 10%

C3706 2311049J11 CAPACITOR TANT 10% 4.7UF

C3707 2113743N34 22.0 PF 5%

C3708 2113743M24 100000 PF +80-20% Y5V

C3709 2113743M24 100000 PF +80-20% Y5V

C3710 2104993J02 MONOLITH CERAMIC (2.2UF)

C3711 2311049A69 TAN CHIP 10.0 UF 20% 6.3V

C3712 2113743M24 100000 PF +80-20% Y5V

C3713 2311049A09 TANT 2.2 UF 10%

C3714 2311049J11 CAPACITOR TANT 10% 4.7UF

C3715 2113743L09 470 PF 10%

Circuit

Ref

Motorola

Part No

Description

C3721 2113743E20 CHIP. 10 UF 10%

C3722 2113743E20 CHIP. 10 UF 10%

C3724 2311049A08 KEMET CAPS

C3726 2113743N24 8.2 PF + -.5PF

C3727 2113743N50 100 PF 5%

C3731 2113743L41 10000 PF 10%

C3732 2113743L41 10000 PF 10%

C3733 2104993J02 MONOLITH CERAMIC (2.2UF)

C3734 2113743L41 10000 PF 10%

C3742 2113743L01 220 PF 10%

C3743 2113743L01 220 PF 10%

C3744 2113743L01 220 PF 10%

C3745 2113743L01 220 PF 10%

C3746 2113743L01 220 PF 10%

C3752 2113743L17 1000 PF 10%

C3753 2311049A56 TAN CHIP A/P 4.7 20 10

C3754 2113743M24 100000 PF +80-20% Y5V

C3755 2104993J02 MONOLITH CERAMIC (2.2UF)

* C3761 2113743N44 56.0 PF 5%

* C3762 2113740F63 330 CL1 +/-30 5%

* C3763 2113743N08 1.6 PF +-.25PF

C3801 2113743N18 4.7 PF +-.25PF

C3803 2113743L17 1000 PF 10%

C3804 2113743E20 CHIP. 10 UF 10%

C3805 2113743N18 4.7 PF +-.25PF

C3806 2113743N50 100 PF 5%

C3808 2113743N30 15.0PF 5%

C3809 2113743N36 27.0 PF 5%

C3811 2113743M24 100000 PF +80-20% Y5V

C3812 2113743M24 100000 PF +80-20% Y5V

C3813 2113743L41 10000 PF 10%

C3815 2113743L17 1000 PF 10%

C3816 2113743N22 6.8 PF +-.5PF

C3818 2113743E07 .022UF

C3821 2113743L41 10000 PF 10%

C3822 2113743L17 1000 PF 10%

C3823 2113743L41 10000 PF 10%

C3824 2113743N44 56.0 PF 5%

C3825 2113743N30 15.0PF 5%

C3826 2113743N18 4.7 PF +-.25PF

C3827 2113743E07 .022UF

C3828 2109720D01 LOW DIS T .01UF

C3829 2109720D01 LOW DIS T .01UF

C3830 2113743N46 68.0 PF 5%

C3832 2113743L17 1000 PF 10%

C3833 2113743N18 4.7 PF +-.25PF

C3834 2113743N44 56.0 PF 5%

C3835 2113743N22 6.8 PF +-.5PF

C3836 2113743N30 15.0PF 5%

C3842 2113743L17 1000 PF 10%

C400 2113743L41 10000 PF 10%
