Motorola MBP35 User Manual

10 Getting started
NOTE
Once the baby and parent units are switched on, the display on the parent
unit will show the video captured by the baby unit.
When there is no connection or out of range, the icon on the LCD
display will flash and the parent unit will beep continuously. Move the
parent unit closer to the baby unit until the link is re-established.
2.5 Registration
The baby monitor is already pre-registered upon your purchase. You do
not need to re-register it again unless the baby unit loses its link with the
parent unit.
To re-register your baby monitor, follow the procedure below:
1. Switch off both the baby and parent units.
2. Press and hold
m for more than 5 seconds while the parent unit
mains power is switched back on, and then press
p at the same
time to switch it on. The parent unit is in registration mode.
3. Cover the camera lens on the baby unit with a black cloth or bag and
then switch it on.
4. Wait for the 2 units to search and establish the link.
5. Remove the cover on the baby unit.
The registration is complete when the display screen on the parent unit
captures the video from the baby unit’s camera.

Motorola MBP35 Specifications

General

LED type	IR
Night mode	Yes
Sensor type	CMOS
Fixed focal length	2.5 mm
Number of illumination LEDs	8
Maximum range	122 m
Smartphone support	No
Number of lullabies	5
Interface	-
Frequency band	2.4 - 2.4835 GHz
Product color	Grey, Silver
LED indicators	Power
Display diagonal	3.5 \
Display number of colors	16.78 million colors
AC input voltage	230 V
DC input voltage	6 V
Power source type	AC, Battery
AC input frequency	50 Hz
Battery technology	Nickel-Metal Hydride (NiMH)
