There are two situations where these retrofit kits are used. The first is
where the radio body remains where it is presently located (e.g., under
the front seat or on the transmission hump) and just the control head
is moved to a different location (e.g., under the dashboard). The other
situation is where both the radio body and the control head are moved
to different locations.
Retrofit Kit
Applicability
Kit No. H1634( )
Retrofit kit No. H1634( ) is applicable to MCS 2000 Model I Radio
Models M01UGL6PW4_N (15W) and M01UJL6PW4_N (35W).
Kit No. H1635( )
Retrofit kit No. H1635( ) is applicable to: MCS 2000 Model II Radio
Models M01UGM6PW6_N (15W) and M01UJM6PW6_N (35W); and
to MCS 2000 Model III Radio Models M01UGN6PW6_N (15W);
M01UJN6PW6_N (35W).
Reference
Publications
Refer to Installation Instructions Manual for MCS 2000 Mobile Radios,
Motorola Stock No. 68P02058U20, for installation information not
included in these retrofit instructions.
Retrofit Kit
Contents
Kit No. H1634( )
Contents
The contents of Retrofit Kit No. H1634( ) are listed in Table 1 below.
Note from Table 1 that several items in the retrofit kit are themselves
kits, which contain two or more items.
Table 1 Contents of Retrofit Kit No. H1634( )
Part No. Description Quantity
GLN7290( ) Kit containing: control head back housing and
front gasket
1
GLN7291( ) Kit containing: transceiver front housing;
connector-header; and retainer
1
HKN4192( ) Kit containing: remote mount power cable (7-
meters long) and fuse adapter
1
HKN6112( )
or
HKN6098( )
Remote mount control head cable (5-meters
long)
1
HLN6599( ) Kit containing: control head trunnion; two (2)
wing screws; two (2) fillister head screws; and
two (2) connector gaskets
1
