Chapter 1
1-31 Getting Started
OC_SWITCH1: OC Genie Mode Switch
This swtich provides two overclocking modes (Gear 1 and Gear 2) for OC Genie
operation. When you press the OC Genie button, the overclocking procedure will
be performed according to the setting of this switch. The Gear 1 mode is the default
setting. The Gear 2 mode allows the OC Genie function to overclock the CPU/ system
frequency higher then Gear 1.
Red LED
Gear 1
(Default)
Gear 2
Blue LED
SLOW_MODE: Slow Mode Booting Switch
This switch is used for LN2 cooling solution, that provides the extreme overclocking
conditions, to boot at a stable processor frequency and to prevent the system from
crashing.
Normal
(Default)
Enabled
Important
Users will try extreme low temperature overclocking at their own risks. The
overclocking results will vary according to the CPU version.
