MSI B250 GAMING PRO CARBON User Manual

32
Overview of Components
M.2 slots with examples of various combination possibilities
PCIe SATA
SATA
PCIe
PCIe
SATA PCIe
SATA
SATA4 SATA4
SATA4
SATA4
SATA5 SATA5 SATA6
SATA6 SATA5
SATA5
SATA2 SATA2
SATA2
SATA2
SATA1
SATA1
SATA3 SATA3
SATA3
SATA3
1xM.2 PCIe SSD + 1xM.2 SATA SSD + 5xSATA HDDs
2xM.2 SATA SSDs + 4xSATA HDDs
2xM.2 PCIe SSDs + 6xSATA HDDs
JFP1, JFP2: Front Panel Connectors
These connectors connect to the switches and LEDs on the front panel.
1
2 10
9
JFP1
1 HDD LED + 2 Power LED +
3 HDD LED - 4 Power LED -
5 Reset Switch 6 Power Switch
7 Reset Switch 8 Power Switch
9 Reserved 10 No Pin
1
JFP2
1 Speaker - 2 Buzzer +
3 Buzzer - 4 Speaker +
or
