MSI B250M BAZOOKA User Manual

23
Overview of Components
Component Contents
Port Name Port Type Page
CPU_FAN1~2,SYS_FAN1~4 Fan Connectors 31
CPU_PWR1, ATX_PWR1 Power Connectors 29
CPU Socket LGA1151 CPU Socket 24
DIMMA1, DIMMA2,
DIMMB1,DIMMB2
DIMM Slots 25
JAUD1 Front Audio Connector 28
JBAT1 Clear CMOS (Reset BIOS) Jumper 34
JCI1 Chassis Intrusion Connector 32
JCOM1 Serial Port Connector 28
JFP1, JFP2 Front Panel Connectors 28
JLED1 RGB LED connector 33
JLPT1 Parallel Port Connector 33
JTPM1 TPM Module Connector 32
JUSB1 USB 3.1 Gen1 Connectors 30
JUSB2~3 USB 2.0 Connectors 30
M2_1 M.2 Slot (Key M) 27
PCI_E1~3 PCIe Expansion Slots 26
SATA1~6 SATA 6Gb/s Connectors 26

MSI B250M BAZOOKA Specifications

General

Form Factor	Micro ATX
Chipset	Intel B250
Socket	LGA 1151
Maximum Memory	64GB
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 3.0 x1
Storage Interface	6 x SATA 6Gb/s
Memory Slots	4
M.2 Slots	1 x M.2
USB Ports	6 x USB 3.1 Gen1 (4 rear, 2 via header), 6 x USB 2.0 (2 rear, 4 via headers)
Audio	Realtek ALC887
LAN	Realtek 8111H
RAID Support	0, 1, 5, 10
