MSI B650M PROJECT ZERO User Manual

36

󼜃󼒆󻺞󽍟
󻢚󻋒󼗶󼓂󼳲󼕦󻰆󼕦󼗶󼓂󺫧󺯻󼖗󼱊󼏂󼐞󻨆󻝦󺩾󼏢󺪢󻈊󼎦󻡆󼕪󻫦󻋎󺧲󼌺󼘇󼗳󼔮󻙎
󼖃󻇋󽍊󻂆󼞲󽑇󼕪󽍊󼃟󼃎󼐖
󼗶󼓂󼳖󺼗󼼢
󼕦󼳖󺼗󼼢󻝮󻺞󼒛󽍊󼏞󼗶󼓂󺫧󺯻󼖗󼱊󻝮󼏢󺪢󽍒󼀊󼕺󼂧󻂺󻃖
CPU_PWR1~2
󽌲 󼃒󽐪󼕦󻝶 󽌲 󼃒󽐪󼕦󻝶
1 Ground 2 Ground
3 Ground 4 Ground
5 +12V 6 +12V
7 +12V 8 +12V
ATX_PWR1
󽌲 󼃒󽐪󼕦󻝶 󽌲 󼃒󽐪󼕦󻝶
1 +3.3V 2 +3.3V
3 Ground 4 +5V
5 Ground 6 +5V
7 Ground 8 PWR OK
9 5VSB 10 +12V
11 +12V 12 +3.3V
13 +3.3V 14 -12V
15 Ground 16 PS-ON#
17 Ground 18 Ground
19 Ground 20 Res
21 +5V 22 +5V
23 +5V 24 Ground
5
4 1
8
CPU_PWR1~2
24
131
12
ATX_PWR1
