2-8 2-9
Left Side View
1. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air
circulation.
2. RJ-45 Connector
The Ethernet connector, with optionally supported transmitting rate of
10/100/1000/2500 megabits per second, is used to connect a LAN cable for network
connection.
3. USB 3.2 Gen 2 Port
USB 3.2 Gen 2, the SuperSpeed USB 10Gbps, supports high-speed data transfer for
connected devices, such as storage devices, hard drives, or video cameras.
4. Power Connector
This connector is to connect the AC/DC adapter and supply power for the notebook.
5. Combo Audio Port
• A port for a headset, microphone, or headset with
microphone.
• The Combo Audio Port supports 4-Pole 3.5mm
headphone jack.
