MSI H310M PRO-VDH PLUS User Manual

13
󶳧󱝾󴘭󸵅 󶳧󱝾󴘭󸵅
JTPM1: TPM 󴝙󶳧󳰛󱿂
󴦞󳰛󱿂󴂞󵫞󴊜󸴗󳰛 TPM (󲶿󾇄󳌣󱿖󴝙󶳧)󸛝󱾍󶻭 TPM 󲶿󾇄󳌣󱿖󳧼󱯤󱝤󷛇󳕅󴇠󲡖󶳩󷐽󲃅
󵫞󴰢
1
2 14
13
1 LPC Clock 2 3V Standby power
3 LPC Reset 4 3.3V Power
5 LPC address & data pin0 6 Serial IRQ
7 LPC address & data pin1 8 5V Power
9 LPC address & data pin2 10 No Pin
11 LPC address & data pin3 12 Ground
13 LPC Frame 14 Ground
JCOM1: 󱙏󸀅󶔏󲢃󳰛󱿂
󴦝󳰚󱿂󱭩󸚞󳜁󸴗󳰚󱿔󸶆󱙏󸀅󶔏󱿂󱿔󵫞󳱤󴜖
1
2 10
9
1 DCD 2 SIN
3 SOUT 4 DTR
5 Ground 6 DSR
7 RTS 8 CTS
9 RI 10 No Pin
󶘮󴁳󱢉󹜂 LED 󵉉
LED 󳬙󶆻󵉉󲔩󱙛󴋃󱙆󵵙󵚱󳗷
CPU - 󸀮󶆻 CPU 󴀞󴰢󴓍󴳖󳦕󳼇󹤜
DRAM - 󸀮󶆻 DRAM 󴀞󴰢󴓍󴳖󳦕󳼇󹤜
VGA - 󸀮󶆻 GPU 󴀞󴰢󴓍󴳖󳦕󳼇󹤜
BOOT - 󸀮󶆻󲀹󱶴󸚤󲠫󴀞󴰢󴓍󴳖󳦕󳼇󹤜
Downloaded from ManualsNet.com search engine

MSI H310M PRO-VDH PLUS Specifications

General

Processor socket	LGA 1151 (Socket H4)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Pentium
Intel® Core i3/i5/i7/i9 series	i3-8xxx, i5-8xxx, i7-8xxx
Maximum number of SMP processors	1
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H310
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Number of mounting holes	6
Windows operating systems supported	Windows 10
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	2133, 2400, 2666 MHz
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	SATA III
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	-
BIOS type	UEFI AMI
Number of SATA III connectors	4
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi	No
LAN controller	Realtek RTL8111H
Ethernet interface type	Gigabit Ethernet
Cables included	SATA

Weight and Dimensions

Depth	185 mm
Width	226 mm
