MSI H310M PRO-VDH PLUS User Manual

3
Safety Information Specifications
Specifications
CPU
Supports 8th Generation Intel
®
Core™ Processors, Pentium
®
Gold and Celeron
®
Processors for Socket LGA1151
Chipset
Intel
®
H310 Chipset*
* This chipset is ME11 firmware based and doesn󾙓t feature
SDA3.0.
Memory
y 2x DDR4 memory slots, support up to 32GB*
y Supports DDR4 2666/ 2400/ 2133 MHz (by JEDEC)**
y Supports DDR4 2666/ 2400/ 2133 MHz (by XMP OC)**
y Supports Dual-Channel mode
y Supports non-ECC, un-buffered memory
y Supports Intel
®
Extreme Memory Profile (XMP)
* Please refer www.msi.com for more information on
compatible memory.
** 2666 MHz for I7 and I5 processors only.
Expansion Slots
y 1x PCIe 3.0 x16 slot
y 2x PCIe 2.0 x1 slots
Onboard
Graphics
y 1x VGA port, supports a maximum resolution of
2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz
y 1x DVI-D port, supports a maximum resolution of
1920x1200@60Hz
y 1x HDMI™ port, supports a maximum resolution of
4096x2160@30Hz
* Supports up to 2 displays simultaneously.
Storage
Intel
®
H310 Chipset
y 4x SATA 6Gb/s ports
 Supports Intel
®
Rapid Storage Technology
USB
Intel
®
H310 Chipset
y 4x USB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports
on the back panel, 2 ports available through the internal USB
connector)
y 6x USB 2.0 (High-speed USB) ports (4 ports on the back
panel, 2 ports available through the internal USB connector)
Audio
y Realtek
®
ALC887/ ALC892/ ALC897 Codec
y 7.1-Channel High Definition Audio
LAN 1x Realtek RTL8111H Gigabit LAN controller
Continued on next page
Downloaded from ManualsNet.com search engine

MSI H310M PRO-VDH PLUS Specifications

General

Processor socket	LGA 1151 (Socket H4)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Pentium
Intel® Core i3/i5/i7/i9 series	i3-8xxx, i5-8xxx, i7-8xxx
Maximum number of SMP processors	1
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H310
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Number of mounting holes	6
Windows operating systems supported	Windows 10
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	2133, 2400, 2666 MHz
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	SATA III
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	-
BIOS type	UEFI AMI
Number of SATA III connectors	4
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi	No
LAN controller	Realtek RTL8111H
Ethernet interface type	Gigabit Ethernet
Cables included	SATA

Weight and Dimensions

Depth	185 mm
Width	226 mm
