JUSB2: USB 3.1 Gen1 󼱓󺺔󼺟
󼓣 󼱓󺺔󼺟󻛫 󻸛󼐘󽋇󼍛 󼕳󻟣 󽂗󺹿󼓇 USB 3.1 Gen1 󽅛󽀧󻛫 󼍟󺨟󽋏 󻾇 󼓷󼀤󻀷󻁓.
1
10
11
20
1 Power 11 USB2.0+
2 USB3_RX_DN 12 USB2.0-
3 USB3_RX_DP 13 Ground
4 Ground 14 USB3_TX_C_DP
5 USB3_TX_C_DN 15 USB3_TX_C_DN
6 USB3_TX_C_DP 16 Ground
7 Ground 17 USB3_RX_DP
8 USB2.0- 18 USB3_RX_DN
9 USB2.0+ 19 Power
10 NC 20 No Pin
󼚀󼐃󻸛󽋜
󼕳󼐿 󻥾 󺭧󻓫󼐣󻉋 󽊯󼒳 󼖄󽏄󽓷 󼍟󺨟󽋇󼍛󼋫 󻻿󻸰󼒳 󻦘󼜯󽋏 󻾇 󼓷󼀤󻀷󻁓.
JUSB1: USB 2.0 󼱓󺺔󼺟
󼓣 󼱓󺺔󼺟󻛫 󻸛󼐘󽋇󼍛 󼕳󻟣 󽂗󺹿󼓇 USB 2.0 󽅛󽀧󻛫 󼍟󺨟󽋏 󻾇 󼓷󼀤󻀷󻁓.
1
2 10
9
1 VCC 2 VCC
3 USB0- 4 USB1-
5 USB0+ 6 USB1+
7 Ground 8 Ground
9 No Pin 10 NC
󼚀󼐃󻸛󽋜
y VCC 󻥾 󺭧󻓫󼐣󻉋 󽊯󼒳 󼖄󽏄󽓷 󼍟󺨟󽋇󼍛󼋫 󻻿󻸰󼒳 󻦘󼜯󽋏 󻾇 󼓷󼀤󻀷󻁓.
y USB 󽅛󽀧󻛫 󼼤󽋇󼍛 iPad,iPhone 󻥾 iPod󻛫 󼬘󼕳󽋇󻖓󻟣 MSI® SUPER CHARGER
󼒏󽁧󻜛󽁟󻛫 󻺓󼯇󽋇󼁋󺮟 󻦃󻓼󻀷󻁓.
Downloaded from ManualsNet.com search engine

MSI H310M PRO-VDH PLUS Specifications

General

Processor socket	LGA 1151 (Socket H4)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Pentium
Intel® Core i3/i5/i7/i9 series	i3-8xxx, i5-8xxx, i7-8xxx
Maximum number of SMP processors	1
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H310
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Number of mounting holes	6
Windows operating systems supported	Windows 10
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	2133, 2400, 2666 MHz
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	SATA III
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	-
BIOS type	UEFI AMI
Number of SATA III connectors	4
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi	No
LAN controller	Realtek RTL8111H
Ethernet interface type	Gigabit Ethernet
Cables included	SATA

Weight and Dimensions

Depth	185 mm
Width	226 mm
