Important
To ensure system stability for Dual channel mode, memory modules must be of the same type, number and
density.
Some memory modules may operate at a lower frequency than the marked value when overclocking due to the
memory frequency operates dependent on its Serial Presence Detect (SPD). Go to BIOS and find the DRAM
Frequency to set the memory frequency if you want to operate the memory at the marked or at a higher
frequency.
It is recommended to use a more efficient memory cooling system for full DIMMs installation or overclocking.
The stability and compatibility of installed memory module depend on installed CPU and devices when
overclocking.
Please refer to www.msi.com for more information on compatible memory.
M2_1: M.2 Slot (Key M)
Please install the M.2 device into the M.2_1 slot as shown below.
M2_2: M.2 Slot (Key E)
Please install the Wi-Fi module into M.2_2 slot as shown below.
PCI_E1~2: PCIe Expansion Slots
