MSI H510M PRO User Manual

The motherboard has been dropped and damaged.
The motherboard has obvious sign of breakage.
Do not leave this motherboard in an environment above 60°C (140°F), it may damage the motherboard.
Specifications
CPU
Supports 10th Gen Intel® Core™ Processors, 11th Gen Intel® Core™
Processors, Pentium® Gold and Celeron® Processors
Processor socket LGA1200
* Please go to intel.com for compatibility information.
Chipset Intel® H510/ B560 chipset
Memory
2x DDR4 memory slots, support up to 64GB*
Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel® CPU (by JEDEC
& POR)
Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel® CPU (by
JEDEC & POR)
Max overclocking frequency (For B560M PRO-E/ B560M PLUS/ B560M-
X):
1DPC 1R Max speed up to 4800 MHz
1DPC 2R Max speed up to 4600+ MHz
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile (XMP)
* Please refer to www.msi.com for more information on compatible memory.
Expansion Slots
1x PCIe x16 slot (From CPU)
Support up to PCIe 4.0 for 11th Gen Intel® CPU
Support up to PCIe 3.0 for 10th Gen Intel® CPU
1x PCIe 3.0 x1 slot (From PCH)
1x M.2 slot with E key for WiFi module only(M2_2) (For H510M PRO/
H510M-A PRO/ H510M BOMBER)
Onboard Graphics
1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K
60Hz*/**
1x VGA port, supports a maximum resolution of 2048×1536 60Hz,
1920×1200 60Hz (For H510M PRO/ H510M-A PRO/ H510M BOMBER/
B560M PRO-E/ B560M-X)*
1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz (For
H510M PRO)*/**
* Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the CPU installed.
Audio
Realtek® ALC897 Codec
7.1-Channel High Definition Audio
LAN 1x Intel® I219V 1Gbps LAN controller

MSI H510M PRO Specifications

General

Processor socket	LGA 1200 (Socket H5)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Maximum number of SMP processors	1
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2666, 2933, 3200 MHz
Supported storage drive types	HDD & SSD
Number of storage drives supported	5
Supported storage drive interfaces	M.2, SATA
DirectX version	12.0
Maximum resolution	4096 x 2304 pixels
Parallel processing technology support	Not supported
Number of SATA III connectors	4
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
USB connector type	USB Type-A
DisplayPort version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi	No
LAN controller	Intel® I219-V
Ethernet interface type	Gigabit Ethernet
Audio chip	Realtek ALC897
Component for	PC
Motherboard chipset	Intel H510
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Number of mounting holes	6
Windows operating systems supported	Windows 10 x64
BIOS type	UEFI AMI
Cables included	SATA
Harmonized System (HS) code	84733020
Weight	730 g

Weight and Dimensions

Depth	202 mm
Width	236 mm
Height	60 mm
