16
Specifications
CPU
∙ Supports AMD Ryzen™ 7000 Series Desktop Processor*
∙ Supports Processor socket AM5
* Please go to www.msi.com to get the newest support status as new processors
are released.
Chipset AMD B650 chipset
Memory
∙ 4x DDR5 memory slots, supporting up to 128GB*
∙ Supports 1R 4800 MHz by JEDEC
∙ Max overclocking frequency:
• 1DPC 1R Max. speed up to 6400+ MHz
• 1DPC 2R Max. speed up to 5800+ MHz
• 2DPC 1R Max. speed up to 6000+ MHz
• 2DPC 2R Max. speed up to 4000+ MHz
∙ Supports Dual-Channel mode
∙ Supports non-ECC, un-buffered memory
∙ Supports AMD EXPO
* Please refer to www.msi.com for more information on compatible memory.
Expansion Slots
∙ 2x PCIe x16 slots
• PCI_E1 slot (From CPU)
• Supports up to PCIe 4.0 x16
• PCI_E3 slot (From B650 chipset)
• Supports up to PCIe 4.0 x4
∙ 1x PCIe x1 slot
• PCI_E2 slot (From B650 chipset)
• Supports up to PCIe 3.0 x1
Onboard Graphics
∙ 1x HDMI™ 2.1 port with HDR, supporting a maximum
resolution of 4K 60Hz*/ **
∙ 1x DisplayPort 1.4 port with HBR3, supporting a maximum
resolution of 8K 60Hz*/ **
* Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the CPU installed.
SATA Ports
∙ 6x SATA 6Gb/s ports
• SATA_1_2 & SATA_3_4 (From B650 chipset)
• SATA_A1_A2 (From ASM1061)
Continued on next column
