Overview of Components
V-Check Points Lite
These voltage checkpoints are used to measure the current system voltages. A
multimeter (not included) will be required to check voltages. To measure voltage,
Please refer to the manual of your multimeter for more information.
T_SEN1~2: Thermal Sensor Connector
This connector allows you to connect the thermistor cable and use it to monitor the
temperature of the detection point.
Thermistor cable
(optional)
GND
Sense
CPUVDD2
CPU_AUX
GND
VCC
SOCKET
To Next Page
