25
Overview of Components
Overview of Components
CPUFAN1
CPUFAN2
PCI_E1
PCI_E2
PCI_E3
JBAT1
PCI_E4
PCI_E5
PCI1
PCI_E6
CPU SocketJPWR2
M2_1
DIMM1
SYSFAN1 DIMM2
DIMM3
DIMM4
JUSB1
JUSB2
JFP1
JFP2
SYSFAN2
JAUD1
JTPM1
SYSFAN3
JPWR1
JUSB3
SATA5
SE1_21
JCI1
SATA6
SATA4
SATA3
JTBT1*
* JTBT1 is used to connect a specific card.
EZ Debug LED
