MSI Z270 gaming M3 User Manual

16
Specifications
Specifications
CPU
Supports 6th/7th Gen Intel
®
Core™ i3/i5/i7 processors,
and Intel
®
Pentium
®
and Celeron
®
processors for Socket
LGA1151
Chipset Intel
®
Z270/ H270/ B250 Chipset
Memory
y
4x DDR4 memory slots, support up to 64GB

Z270 chipset + 7th Gen processors support DDR4
3800(OC)/ 3600(OC)/ 3200(OC)/ 3000(OC)/ 2800(OC)/
2600(OC)/ 2400/ 2133 MHz*

Z270 chipset + 6th Gen processors support DDR4
3600(OC)/ 3200(OC)/ 3000(OC)/ 2800(OC)/ 2600(OC)/
2400(OC)/ 2133 MHz*

H270/ B250 chipset + 7th Gen processors support DDR4
2400/ 2133 MHz*

H270/ B250 chipset + 6th Gen processors support DDR4
2133 MHz*
y
Dual channel memory architecture
y
Supports Intel
®
Extreme Memory Profile (XMP)
* Please refer www.msi.com for more information on compatible memory.
Expansion Slots
y 2x PCIe 3.0 x16 slots (supports x16/x4 mode)*
y 4x PCIe 3.0 x1 slots**
* The PCI_E4 slot will be unavailable when an M.2 SSD module has been
installed in the M.2_2 slot.
** The PCI_E2 slot will be unavailable when an expansion card has been
installed in the PCI_E5 slot.
** The PCI_E3 slot will be unavailable when an expansion card has been
installed in the PCI_E6 slot.
Onboard Graphics
y 1x HDMI™ port, supports a maximum resolution of
4096x2160@30Hz(7th CPU), 4096x2160@24Hz(6th CPU),
2560x1600@60Hz
y 1x DVI-D port, supports a maximum resolution of
1920x1200@60Hz
Multi-GPU Supports 2-Way AMD
®
CrossFire™ Technology
Continued on next page

MSI Z270 gaming M3 Specifications

General

Chipset	Intel Z270
CPU Socket	LGA 1151
Form Factor	ATX
Memory Slots	4
Max Memory	64 GB
Memory Type	DDR4
Audio	Realtek ALC892
RAID Support	RAID 0, 1, 5, 10
Memory Speed	2133/ 2400/ 2800/ 3000/ 3200/ 3400/ 3600/ 3800 MHz
Storage Interface	6 x SATA 6Gb/s
USB Ports	6 x USB 2.0
LAN	Intel I219-V
Multi-GPU Support	AMD CrossFire
PCIe Slots	2 x PCIe 3.0 x16, 2 x PCIe 3.0 x1
