MSI Z370 GAMING PRO CARBON User Manual

16
Specifications
Specifications
CPU
Supports 8th Generation Intel
®
Core™ Processors, and Intel
®
Pentium
®
and Celeron
®
Processors for Socket LGA1151
Chipset Intel
®
Z370 Express Chipset
Memory
y 4x DDR4 memory slots, support up to 64GB
y Supports DDR4 4000+(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/
3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/
3000(OC)/ 2800(OC)/ 2667/ 2400/ 2133 MHz Memory
y Supports Dual-Channel mode
y Supports non-ECC, un-buffered memory
y Supports Intel
®
Extreme Memory Profile (XMP)
* Please refer www.msi.com for more information on compatible memory.
Expansion Slots
y 3x PCIe 3.0 x16 slots (support x16/x0/x4, x8/x8/x4 modes)
y 3x PCIe 3.0 x1 slots
Onboard Graphics
y 1x HDMI™ port, supports a maximum resolution of
4096x2160@30Hz, 2560x1600@60Hz
y 1x DisplayPort port, supports a maximum resolution of
4096X2304@24Hz, 3840X2160@60Hz,1920X1200@60Hz
Multi-GPU
y Supports 2-Way NVIDIA
®
SLI™ Technology
y Supports 3-Way AMD
®
CrossFire™ Technology
Storage
Intel
®
Z370 Chipset
y 6x SATA 6Gb/s ports*
y 2x M.2 slots (Key M)
 Support up to PCIe 3.0 x4 and SATA 6Gb/s
 Support PCIe 3.0 x4 NVMe U.2 SSD with Turbo U.2 Host
Card**
 M2_1 slot supports 2242/ 2260 /2280/ 22110 storage
devices
 M2_2 slot supports 2242/ 2260 /2280 storage devices
 Intel
®
Optane™ Memory Ready for all M.2 slots***
* M.2 and SATA ports maximum support 1x M.2 PCIe SSD + 1x M.2 SATA SSD +
5x SATA HDDs. Please refer to page 34 for M.2 slots with examples of various
combination possibilities.
** The Turbo U.2 Host Card is not included, please purchase separately.
*** Before using Intel
®
Optane™ memory modules, please ensure that you have
updated the drivers and BIOS to the latest version from MSI website.
Continued on next page

MSI Z370 GAMING PRO CARBON Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 4000 MHz
Audio chip	Realtek ALC1220
Cooling type	Passive
Component for	PC
Motherboard chipset	Intel® Z370
PC health monitoring	CPU, FAN, Power supply, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	ATX
Motherboard chipset family	Intel
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Parallel processing technology support	2-Way CrossFireX, 2-Way SLI, 3-Way CrossFireX
Processor socket	LGA 1151 (Socket H4)
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
Number of M.2 (M) slots	2
PCI Express x1 (Gen 3.x) slots	3
BIOS type	UEFI
Cables included	SATA
LAN controller	Intel® I219-V
Ethernet interface type	Gigabit Ethernet
Number of SATA connectors	6
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	- mm
Width	243 mm
Height	304 mm
