mycom 200SUD User Manual

Chapter 7 Related Documents
UD-series Screw Compressor 7.7 Gaskets Used
7-39
7.7 Gaskets Used
Figure 7-9
Gaskets Used
Table 7-19 Gasket Size （㎜）
P/N Location 160 200 250 320
6 Suction Cover
H
354
420
525
660
W
460
560
700
880
12 Bearing Head
H
345
420
525
660
W
460
560
700
880
17
Bearing Cover
H
338
414
505
641
(D: Sideways discharge)
W
397
591
709
887
17
Bearing Cover
H
332.5
380
463
―
(G: Downward discharge)
W
388
480
580
―
23 Balance Piston Cover
H
270
333
340
517
W
283
350
420
532
52
Seal Cover
Φ 140 170 200 250
93 Suction Flange Φ
173
(125A)
198
(150A)
325
(250A)
421
(350A)
96 Discharge Flange Φ
143
(100A)
173
(125A)
198
(150A)
250
(200A)
216 Lubricating Oil inlet Flange Φ
―
44
(20A)
51
(25A)
67
(40A)
219 Oil Injection Flange Φ
― ― ―
51
(25A)
236 Discharge Flange Spacer Φ
110
(100CD)
146
(125CD)
176
(150CD)
233
(200CD)
252 Economizer Flange Φ
51
(25A)
59
(32A)
83
(50A)
118
(80A)
255 Liquid injection Flange Φ
44
(20A)
51
(25A)
59
(32A)
83
(50A)
602
Lubricating Oil (for F Rotor side
Bearing) inlet Flange
Φ
―
― ―
44
(20A)
