2200Q2JE-HO-KHM-N_2015.02.
Chapter 2 Product Specifications and Structure
Ammonia Semi-hermetic Motor with K-series Compressor 2.4 Structure of Semi-hermetic Motor
2-8
No.
Part Name Qty Remarks
621 Gasket, Motor End Cover 1
622 Fastening Bolt, Motor End Cover 8 M8×25
623 Motor Sealing Terminal Box 1
624 Gasket, Motor Sealing Terminal Box 1
625 Fastening Bolt, Motor Sealing Terminal Box 6 Hexagon Head Cap Screw M12×35
626 Motor Terminal Block 1
627 Gasket, Motor Terminal Block 1
628 Fastening Bolt, Motor Terminal Block 8 Hexagon Head Cap Screw M12×35
629 Motor Terminal Box 1
630 Gasket, Motor Terminal Box 1
631 Fastening Bolt, Motor Terminal Box 6 Hexagon Head Cap Screw M8×15
631-1 Fastening Bolt Washer, Motor Terminal Box 6 Nominal 8
631-2 Fastening Bolt Spring Washer, Motor Terminal Box 6 Nominal 8
632 Motor Terminal Box Cover 1
633 Gasket, Motor Terminal Box Cover 1
634 Fastening Screw, Motor Terminal Box Cover 6
Cross recessed hexagon head
screw with captive washer
M5×15
635 Aluminum Terminal V-shaped type 4 Φ16 v-08
636 Aluminum Terminal H-shaped type 2 Φ16 h-08
637 Mounting Nut, Aluminum Terminal 6 M16
637-1 Mounting Washer, Aluminum Terminal 6 Nominal 16
637-2 Mounting Spring Washer, Aluminum Terminal 6 Nominal 16
638 Teflon Parts 1 for Aluminum Terminal 6 1v7_4
638-1 O-ring (NBR) 6 JIS B 2401 P16
638-2 O-ring (NBR) 6 JIS B 2401 P22
639 Teflon Parts 2 for Aluminum Terminal 6 2v7_4
640 Thermometer Terminal 2 NPT1/8
641 Aluminum Crimp Terminal 6
642 Aluminum Bolt 6 M8×35 Special Bolt
643 Aluminum Nut 12 M8 Special Nut
643-1 Aluminum Washer 6 Special washer (exclusive)
699 Eye Bolt for Motor 2 M12
HKF Water Flange 2 15A
HKFG Gasket, Water Flange 2
HKFB Fastening Bolt, Water Flange 4 M10×L20 (SUS)
JO4030 Half Union Joint I-type 1 R1/4×Φ8
JO4050 Half Union Join L-type 2 R1/4×Φ8
PI1 Piping 1 Φ8×115mm
JO4050 Half Union Join L-type (attach to Motor Spacer) 2 R1/4×Φ8
PI2 Oil supply/Return Piping for Motor Bearing 2 Φ8×1000mm
To Next Page
