9.0 REPLACEMENTS
Contact your dealer or the factory for questions concerning prices and policies on replacement parts. Normally
all parts can be ordered through your Authorized dealer / distributor.
FOR WARRANTY REPLACEMENT PARTS, A PHOTOCOPY OF THE
ORIGINAL INVOICE WILL BE REQUIRED TO HONOUR THE CLAIM.
When ordering replacement parts always give the following information:
• Model & Serial Number of appliance
• Installation date of appliance
• Part number
• Description of part
• Finish
* IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED. FOR FURTHER INFORMATION, CONTACT YOUR
AUTHORIZED DEALER.
41.1
FAILURE TO POSITION THE PARTS
IN ACCORDANCE WITH THIS
MANUAL OR FAILURE TO USE ONLY
PARTS SPECIFICALLY APPROVED
WITH THIS APPLIANCE MAY
RESULT IN PROPERTY DAMAGE OR
PERSONAL INJURY.
!
WARNING
COMPONENTS
REF # S1 S4 S9 DESCRIPTION
1 W225-0313 W225-0313 W225-0313 DOOR
2 W300-0168 W300-0168 W300-0168 DOOR, GLASS
3 W500-0709 W500-0709 W500-0709 GLASS RETAINER
4 W495-0048 W495-0048 W495-0049 PEDESTAL BASE
5 W325-0077 W325-0077 W325-0077 DOOR HANDLE
6 W060-0012 W060-0012 W060-0012 LATCH BLOCK
7 W485-0052 W485-0052 W485-0052 DOOR HANDLE PIN
8 W630-0024 W630-0024 W630-0024 SPRING, HANDLE
9 W010-1534 W010-1534 W010-1534 ASH PAN
10 W010-2947 W010-2947 W010-2947 DOOR HINGE
11* W090-0001 W090-0001 W090-0015 BRICK (1.25” x 4.5” x 9”) (31.8mm x 114.3mm x 228.6mm)
12* W090-0016 W090-0016 W090-0016 BRICK (1.25” x 2.5” x 4.5”) (31.8mm x 63.5mm x 114.3mm)
13* W090-0017 W090-0017 W090-0017 BRICK (1.25” x 1.5” x 4.5”) (31.8mm x 38.1mm x 114.3mm)
14* W090-0002 W090-0002 W090-0002 BRICK (1.25” x 3” x 9”) (31.8mm x 76.2mm x 228.6mm) (MOLDED)
15* W090-0207 W090-0207 W090-0207 BRICK, LEFT SIDE (NOTCHED)
16* W090-0208 W090-0208 W090-0208 BRICK, RIGHT SIDE (NOTCHED)
17* W090-0216 W090-0216 W090-0216 BRICK (1.25” x 1.75 x 4.75”) (31.8mm x 57mm x 121mm)
18* W090-0018 W090-0018 W090-0018 BRICK (1.25” x 2.25” x 9”) (31.8mm x 57mm x 229mm)
19* W090-0003 N/A W090-0003 BRICK (1.25” x 4.5” x 4.5”) (31.8mm x 114.3mm x 190.5mm)
20* W090-0210 W090-0210 W090-0210 BRICK (1.25” x 4.5” x 8.5”) (31.8mm x 114.3mm x 216mm)
21* W018-0077 W018-0078 W018-0130 FIBRE BAFFLE
22 W585-0793 W585-0786 W585-0792 SIDE HEAT SHIELD
23 W135-0238 W135-0238 W135-0238 ASH LIP
24 W010-3043 W010-3043 W010-3043 ASH DRAWER
25 W010-2978 W010-2978 W010-2978 AIR CONTROL
26 W475-0870 W475-0870 W475-0870 REAR PEDESTAL PANEL
27 W500-0696 W500-0696 W500-0718 PEDESTAL PLATE
28 W200-0415 W200-0415 W200-0415 ASH DRAWER TOP COVER
29 W290-0219 W290-0219 W290-0228 MANIFOLD GASKET
30 W432-0131 W432-0129 W432-0130 SECONDARY AIR MANIFOLD
31 W500-0076 W500-0076 W080-0216 RETAINER
32 W200-0414 W200-0414 W200-0414 REAR SHIELD COVER
33 W060-0013 W060-0013 W060-0013 LATCH BLOCK, PIN
34 W065-0041 W065-0041 W065-0041 SHOULDER BOLT
35 W105-0017 W105-0017 W105-0017 CASTING PIVOT BUSHING
36 W325-0082 W325-0082 W325-0082 SLEEVE, HANDLE
37* W610-0010 W610-0010 W610-0010 DRAWER SLIDE
38* W562-0043 W562-0043 W562-0043 GLASS GASKET (1/4” DIA)
39* W562-0002 W562-0002 W562-0002 DOOR GASKET (1/2” DIA)
